DATA 371 Technical data - ETITEC Technical data Type ETITEC COAX 90-TV75-FF; BNC-MF ETITEC COAX 230-TV75-FF; BNC-MF Nominal DC spark-overvoltage V 90 +/- 20% 230 +/- 20% Max. power peak W 40 125 Impedance (Ù) 75 75 Frequence range Mhz 0 - 1600 0 - 1600 Insertion losses dB <0,4 <0,2 Return losses dB >20 >20 Nominal discharge current In (8/20) kA 10 imp. x 5 kA 10 imp. x 5 kA Max. discharge current Imax (8/20) kA 1 imp. x 10 kA 1 imp. x 10 kA Residual voltage (1kV/ys) <600 V <700 V Insulation >10 Gohm >10 Gohm Operating temperature - 40oC ...+80oC Connector TV75-FF (female/ female); F75-MF (male/ female) Technical data Type ETITEC COAX 90-UHF-FF; N-MF ETITEC COAX 230-UHF-FF; N-MF ETITEC COAX 350-UHF-FF; N-MF Nominal DC spark-overvoltage V 90 +/- 20% 230 +/- 20% 350 +/- 20% Max. power peak W 40 125 300 Impedance (Ù) 50 50 50 Frequence range Mhz 0 - 600 0 - 600 0 - 600 Insertion losses dB <0,4 <0,4 <0,4 Return losses dB >20 >20 >20 Nominal discharge current In (8/20) kA 10 imp. x 5 kA 10 imp. x 5 kA 10 imp. x 5 kA Max. discharge current Imax (8/20) kA 1 imp. x 10 kA 1 imp. x 10 kA 1 imp. x 10 kA Residual voltage (1kV/ys) <600 V <700 V <900 V Insulation >10 Gohm >10 Gohm >10 Gohm Operating temperature - 40oC ...+80oC Connector UHF-FF (female/ female); UHF-MF (male/ female) ETITEC COAX UHF-FF ETITEC COAX TV75-FF ETITEC COAX UHF-MF ETITEC COAX TV75-MF LINE SHIELD LINE SHIELD PE LINE SHIELD LINE SHIELD PE
