General The servo gears of the series AP and HP described in this data sheet are

components of the ESR drive packages. These consist of servo amplifiers, servo motors, position sensors, gear boxes, and brakes. They are supplemented by power supply units, connectors, cables (ready-assembled on request), and software. All parts of the package are matched and have been tested as combinations. The delivery of the complete drive system from a single source guarantees smooth installation, reliable operation, and definite system responsibility on the part of one single supplier.

Drive system Our service offer includes individual drive system determination. With our long-

configuration standing experience we help you choose the right servo drive for your

application.

Drive packages AP and HP servo gears are used with AC servo motors in the following drive

packages:

TrioDrive servo drives (data sheet 6646.250)

Shaft power up to 1 kW, servo amplifier with 125 V bus voltage, 19" design with 3 height units, available as single-axis and multi-axis amplifier.

MidiDrive servo drives (data sheet 6661.250)

Shaft power up to 2.6 kW, servo amplifier with 320 V bus voltage, available in compact design (single-axis amplifier) and 19" design with 6 height units (multi-axis amplifier).

TrioDrive D servo drives (data sheet 6750.250)

Shaft power up to 1.4 kW, digital servo amplifier with 320 V bus voltage in compact design (single-axis amplifier), integrated positioning control, fieldbus options.

MidiDrive D servo drives (data sheet 6730.250)

Shaft power up to 3.7 kW, digital servo amplifier with 320 V or 560 V bus voltage in compact design (single-axis amplifier), integrated positioning control, fieldbus options.

MaxiDrive servo drives (data sheet 6710.250)

Shaft power up to 10 kW, digital servo amplifier with 560 V bus voltage in compact design (single-axis amplifier), integrated positioning control, fieldbus options.

The facts given in this data sheet are for information only and are no guarantee of properties. We reserve the right to make changes without notice.
