TrioDrive D/xS and MidiDrive D/xS form a family of particularly compact servo drives, optimized for use in automation networks. But they also do a great job in single-axis applications with operator terminal. The servo drives combine modern servo technology with extensive equipment — at a very attractive price.

■ for use with AC servo motors and direct drives (torque motors, linear motors)

■ with integrated safety technology (category 1 to 4 according to EN 954-1)

■ high processor power for fast axis control and communication

■ switching frequency 8 or 16 kHz selectable for optimum dynamic characteristics and small motor power loss

■ TrioDrive D/ES and MidiDrive D/ES

with EtherCAT interface as standard

-> data sheet 6755.257

■ TrioDrive D/CS and MidiDrive D/CS

with CANopen interface as standard

-> data sheet 6755.252

■ TrioDrive D/PS and MidiDrive D/PS

with Profibus-DP interface as standard

-> data sheet 6755.255

■ TrioDrive D/AS and MidiDrive D/AS

with analog interface and encoder emulation as standard

-> data sheet 6755.250

■ direct mains connection to 230 V~ (wide-range input 85 to 253 V~)

■ three power levels with rated continuous current from 2 to 6 A

■ matching servo motors with up to 12 Nm peak torque, torque motors up to 400 Nm, linear motors up to 960 N peak force

■ direct mains connection to 3 x 400/480 V~ (wide-range input 3 x 85 to 528 V~)

■ five power levels in two sizes with rated continuous current from 2 to 32 A |

■ matching servo motors with up to 160 Nm peak torque, torque motors up to 1600 Nm, linear motors up to 2.2 kN peak force

The established all-rounders: modular construc­tion, optionally with fieldbus interface (Profibus DP, CANopen, or Interbus).

■ direct mains connection to 230 V~

■ rated continuous current from 2 to 6 A

■ servo motors with up to 12 Nm peak torque

-> data sheet 6750.250

■ direct mains connection to 3 x 400/480 V~

■ rated continuous current from 2 to 8 A

■ servo motors with up to 23 Nm peak torque

-> data sheet 6730.250
