Selecting the swing cylinder for your applications

When usingthe standard and long clamp arms from the CAS and CAL series consult the diagrams shown on the next page.When usingTarms use the formula below.

C

Determine the right size of your swing cylinder

Swing cylindersWork supports

Clamp arm length andclamping force

Important

02001

The clamp arms transmit the force generatedby the swing cylinder to the workpiece. Clamparms are available in a variety of lengths. After youhave determined the reuired clamp arm length and the clamping force you can select the swingcylinder type and mounting method. The maximum clamp arm length of a given size ofswing clamp is limited. This limitation is due to the bending moment on the plunger. The bending moment applied to the plunger is a function of thereal clamping force and length of the clamp arm.Never exceed the maximum pressure or flow for any given clamp arm length. Excessive weight willlimit flow.The uniue Enerpac swing clamp and patentedclamp arm guarantee the lowest frictional losses and most efficient clamp design available on themarket today. In the chart below you select therequired clamp arm length and clamping force. The use of different length clamp armsrequires reduction in appliedpressure and resulting clamp force. The diagrams on the next page show this relation. 11 Pivoting Tarms

2

The distribution of the clamparm force is based upon thelength of the T-arm as measured from the pivoting point.

2

For diagrams of allowable oil flow vs Tarm length see: 26

Product selection

ClampClampingForWith armforceSwingClamp ArmlengthCylinderModel numberLF T Model mmkNmin. - max.max. - min
āš drauic iture it sin cinders on to aces orore eicient production
ā–¼ Swing Cylinders SU, SL, ST and SC series 25 - 782,2 - 0,522 CAS, CAL-22 40 - 1305,6 - 1,052 CAS, CAL-52 45 - 1559,0 - 2,292 CAS, CAL-92 51 - 15711,6 - 2,0121, 122 CAS-121, CAL-122 55 - 17318,7 - 4,0202 CAS, CAL-202 68 - 17533,8 - 9,0352 CAS, CAL-352
ā–¼ ColletLokSwing Cylinders MP series 40 - 1004,1 - 1,150 MA-540 50 - 1258,9 - 2,5100 MA-1050 70 - 16037,8 - 9,5300 MA-3070
ā–¼ Pivoting Tarms for SU, SL, ST and SC series swing cylinders 152
1) 2 x2,852 CAC, CAPT-52 203
1) 2 x4,592 CAC, CAPT-92 203
1) 2 x5,8122 CAC, CAPT-122 203
1) 2 x9,3202 CAC, CAPT-202
1) 02002 02002 228 2 x16,9352 CAC, CAPT-352
) Lmax. for T-arms. © 2006
