| SW BA 600 | SW BM 1250 | |||||||||||||||||||
| Horizontal machining center with two or four synchronous, fluid-cooled motor spindles. | Reconfigurable multi-spindle cutter head machine, on which the fixture moves and not the horizontally mounted cutter heads that contain the tools. | |||||||||||||||||||
| Main spindle bearing in hybrid technology. Cycle time-concurrent workpiece changeover. Three NC linear axes and up to four NC rotary axes. 5-sided machining in a single setup. The machine is ideally suited for automatic loading. | A 3-axis workholding unit uses the pick-up principle to collect the workpieces from the loading station and to convey them from one multi-spindle drilling or milling head to the next. The monobloc design offers maximal rigidity, whilst the stationary drilling and milling units guarantee optimal component quality, even under maximum feed force. | |||||||||||||||||||
| Capacity BA600-2 BA600-2G BA600-4 2-spindle 2-spindle 4-spindle X-axistravel mm 600 600 300 Y-axistravel mm 600(975*) 550(975*) 600(975*) Z-axistravel mm 500 360 500 Distance mm 600 600 300 between spindles (*Alternative) | Capacity BM1250 X-axis travel mm 1,900 Y-axistravel mm 1,250 Z-axis travel mm 500 Rapid traverse up to m/min 60 Axisaccelerationupto m/s2 10 Feed force up to kN 28 | |||||||||||||||||||
| 19 | ||||||||||||||||||||
