ElectroCraft RapidPower™, E-Series, EXC-Series, EA-Series & SC-Series

To build your own motor, choose the:

1 - Frame Size 2 - Torque 3 - Winding

( Impérial or Metric )

4 - Features

RI PI 213

7 3

Product Name

Frame Size

Contlnuous Torque *«.

2}\4} — \±\ \Ô\ \Ô\ — \Ç_

HE us m — 1M

Voltage

Rear Front Lead Shaft Shaft Option

Encoder

Product Name

Frame Optional Size Metric

Continuous Torque (Ncm)

Brushless Motor Features

Step 4:

Encoder Options (X = none)

Lead Option

Differential Encoder

0 = No

0 = round

0 = lying leads

J = 500 PPR

C = 500 PPR

1 = Yes

1 = standard lat

1 = standard connecter

K = 1000 PPR

D = 1000 PPR

2 = key seat

L = 2000 PPR

E = 2000 PPR

Encoder Signals

cations for Single

RP Series, E-Series

+5 VDC

GND

CH A

CH B

CH Z

Hall S1

Hall S2

Hall S3

Encoder Specifications for Differential Encoder

RP Series, E-Series


+ 5 VDC	CH A +	CH A -	CH B +	CH B -	CH Z +	CH Z -
GND	Hall S1 +	Hall S1 -	Hall S2 +	Hall S2 -	Hall S3 +	Hall S3 -

EXC34, EXC42 and EXC56*


+5 VDC	+5 VCC Comm	CH A +	CH A -	CH B +	CH B -	CH Z +	CH Z -	Motor TC1
GND Data	GND Comm	Hall S1 +	Hall S1 -	Hall S2 +	Hall S2 -	Hall S3 +	Hall S3 -	Motor TC2

*Encoder drawing not shown as encoder is under a motor cover.
