Communications capabilities - 2

Since 1872, Edwards has been findingbetter ways to alert, warn, and communicate with reliable, high- performance signaling devices. And each year brings more innovations, making industrial, commercial, and institutional locations safer places. Today our innovation has taken aquantum leap forward. Now, for the first time in the history of signaling, you can get complete control of all your signaling in whatever way makes most sense for the way you do business. So not only do we offer you a signal for every signal need, now we also give you a new level ofhands-on control and management for...

Open the catalog to page 2
Communications capabilities - 3

Signaling powered by know-how. Signal Management and Control > Theres a lot more to an Edwards solution than signaling control. You can tap into the industryҒs leading authorities for help and advice for any signaling challenge. Just ask. And if we dont already have a solution, weҒll find one. As you read through this overview, you may verywell find the ideal configuration for yourself. If not, visit us at www.edwards-signals.com or call us at 203.699.3300. And put our proven experience to work for you. Conventional Speaker/ Amplifier Applications SYSTEM PLANNINGSYSTEM PLANNINGSYSTEM...

Open the catalog to page 3
Communications capabilities - 6

There is a tremendous need for integrated andsupervised emergency evacuation and fire systems. Oversight agencies realize this and have either made or are making code changes. In fact, the Occupational Safety and Health Administration (OSHA) has drafted a regulation specifically to address a facilitys emergency action plan and to allow safe escape of employees from the workplace (OSHA Regulation 1910.165).Edwards products Җ Adaptatone > ή System Signals,Millennium System Master , Genesis > Ζ are designedfor both emergency evacuation and general signaling. They can be used by themselves for...

Open the catalog to page 6
Communications capabilities - 7

System Requirements: Windows 98, NT, XP, or 2000. Օ160 MB min. hard drive space with additional space for user-added wav files. 333 MHz processor required, greater than 500 MHz recommended.ՕSound card with mic/line input and speaker outputs. Display with 800x600 minimum resolution. 256 colors recommended. > Signal Management and Control For RS485 Operation: PC must contain at least one Serial COM port orUSB port. Օ You control so much of your job from your com-puter why not your signaling too? It֒s easy with the Millennium Event Driver Interface (MEDI > ).Schedule signals for events as...

Open the catalog to page 7
Communications capabilities - 9

Signaling Devices Versatile and expandable > As your needs grow, so can your AdaptatoneMillennium system. By using a centraltone generatorand simply connecting speaker amplifiers, you can construct a complete system for plant-wide warningand evacuation. Millenniummodels are available in a wide voltage range for non-hazardous and Division2 hazardous locations.Connections are provided forexternal battery backup. Choose from standard 15-watt and high-volume 30-watt units. Division 1models are also available. Get your message heard 27 unique tones that get your message across ֖ soft tones and...

Open the catalog to page 9
Communications capabilities - 10

TM ֮ Millennium Mini-Miis the answer. Low profile and low cost, Mini-Mis modulardesign delivers the perfect solution for any application: speaker/amplifier, stand-alone tone generation, or field-recorded voice operation. Weatherproof and available with RS485 connectivity, Mini-Mi delivers a lot of signaling in a small 6"x5" footprint. The 5560M Mini-Mi is ideal for sounding stand-alone or system tones and voice in factory hallway, office, and personnel areas where the use of a larger device is not desirable. The Mini-Mi may also be used forfire/emergency applications, where audio or voice...

Open the catalog to page 10
Communications capabilities - 12

֙ . 5545M Hazardous LocationRemote Speaker/Amplifier For system use with central tone generator in Division 1 locations. 5510 Remote Audio Signal Converter Converts 25V or 70V RMS input to 10V RMS output. 5533M Hazardous Location Signal Two input, two output signal for Division 1 locations. 5547-15W Re-entrant Speaker 70V input voltage, high sound output. Four power taps 15, 8, 4, and 2 watts. Moisture-resistant. 5535 Remote Amplifier 5538-4 Series Remote Signal Actuator Used when remote speakers are required. Amplifier output is a 70V line with a maximum of 15 watts. Remote activation of...

Open the catalog to page 12
Communications capabilities - 13

XT and XR Transmitters and Receivers 5542RPU Remote Paging Unit Four outputs, high volume, 30-watt heavy-duty industrial signaling device capable of producing volume-controlled,high-decibel tones. Four tones can be activated from field-wired, normally open contacts, or from a 24VDC or 120VAC external voltage source such as the output of a PLC. These RF transmitters are designed for use in wireless remote control applica- tions. When activated with an external dry contact, the transmitter sends a 10-watt, 27.225 MHz digitally encodedFSK (Frequency Shift Keying) signal to a companion...

Open the catalog to page 13
Communications capabilities - 14

Industrial and hazardous locations are nomatch for the 5570 Intercom and speaker. This heavy-duty, two-way communications device is available in 120/240VAC 50/60Hz and 24VAC/DC, so it can fit into just about any communications infrastructure. Voltage input for the 120/240VAC model is internally switch selectable for easy configuration. The ACline has a 1/2 amp 250-volt type GMCfuse. The speakers are rated for 30 Watts, 16Ohms. Their frequency response of 150Hz to 12kHz covers the full range of voice communication.For even more flexibility, you can alsoselect a balanced or unbalanced line...

Open the catalog to page 14
Communications capabilities - 15

6000-S-8-25/70 Series25/70-Volt Baffled Speaker Assemblies High quality units that feature a tastefully constructedsteel baffle that blends well with modern interiors. The speaker assembly includes a dual voltage 70 and 25-volt matching transformer. The transformer has taps of 1/2, 1, 2, and 4 watts at 70 volts and 1/2, 1, and 2 watts at 25 volts. The 15-Watt 6000-15S-8-25/70 has an additional apex whizzer cone for extended high frequency response. The human voice is one of the most challeng- ing sounds to transmit in busy work areas or acoustically reflective rooms. Edwards Public Address...

Open the catalog to page 15
Communications capabilities - 16

Industrial Applications Process Control Applications Institutional Applications Commercial Applications It doesnt matter what your signalingneeds are. Because there is a proven Edwards solution already doing precisely whatever you need to do. Put us to the test and weҒll give you theright signaling answer for any application. Thats why there are more Edwards signals communicating in more applications throughout the world than anyone elseҒs. Our specialty is meeting every signaling challenge. We wouldnt be satisfied with anything less. And neither should you. > 16 size="-2">
