| Data Sheet | ||||||||||||||||||||
| Please read carefully and complete Section A plus the appropriate application section. By doing this you will allow us to propose the best possible solution to enhance your system performance. We suggest you photocopy this form and FAX it to us. | ||||||||||||||||||||
| Company Name | Name | |||||||||||||||||||
| Address _ Telephone | City FAX | State & Zip | ||||||||||||||||||
| A. Product Specifications: Maximum Working Temp._°C (°F) _ Minimum Working Temp. _°C (°F) _ Maximum Working Pressure_bar (psi) _ Minimum Working Pressure _bar (psi) _ Internal Coating _ _ External Coating _ _ Shell Material _ _ Bladder Material _ _ Design Approval _ _ Installation Location (City, Country) _ _ System Fluid _ _ Fluid Port Connection _ _ B. Applications: Fill out the necessary info for desired application. 1. Energy Storage: Volume of Fluid Needed _l (USgal) _ Dual Time (Charge-Discharge) _(sec.) _ Maximum Ambient Temperature _°C (°F) _ Minimum Ambient Temperature _°C (°F) _ Work Cycle Profile (number of stages, time & pressure)_(Enclose drawing or graph) Minimum Working Pressure _bar (psi) _ Maximum Working Pressure_bar (psi) _ 2. Pulsation Dampening: Flow Rate_l/min (USgpm) _ Type of Pump (Piston, Vane, Gear, etc.) _ _ Number of Elements (Pistons, Vanes, Gears, etc.)_ _ Pump Speed_(rpm) _ Working Temperature _°C (°F) _ Working Pressure _bar (psi) _ Pressure Peaks (high and low) _bar (psi) _ Nominal Pipe Size _(inches) _ Maximum Allowable Pressure Drop _bar (psi) _ Minimum Allowable Working Pressure _bar (psi) _ Please call for assistance selecting accumulators for other applications such as suction stabilizing, surge dampening, or thermal expansion. Please return this questionnaire to Eaton by FAX or mail to the attention of Product Technical Support: Eaton Hydraulics, Incorporated • 14615 Lone Oak Road • Eden Prairie, MN • 55344-2287 Phone: (888) 258-0222 / Fax: (952)974-7722 | ||||||||||||||||||||
| •9 | ||||||||||||||||||||
| EATON Accumulators Catalog V-FIFI-MC003-E July 2005 | ||||||||||||||||||||
