ROCKER SWITCHES

EURO/SR Standard Size Euro-Style Rocker Switches

for easy actuation. The EURO/SR will accept loads up to 15A. Terminal numbers are stamped on base for easy identification.

Ratings:

15A @ 125V ac. 10A @ 250V ac. 3/4 Hp @ 250V ac. (Hp rating does not apply to lighted switches.) CUR marked. Recommended up to 15A @ 28V dc.

Field-proven in America's roughest off-road applications, the standard size EURO/SR is one tough and reliable rocker switch. Available with the complete range of rugged one and two-pole, illuminated or non-illuminated circuits. The EURO/SR Series offers snap-in mounting and can be provided with a durable silicone seal which resists dust and moisture. All EURO/SR switches are molded in an aesthetically pleasing matte finish and operate with a crisp tactile feel allowing

Circuits:

1PST, 1PDT, 2PST, and 2PDT Maintained and momentary action.

Contact Mechanism:

Slow-m ake/Slow - break

contact mechanism.

Butt action contact mechanism

designed specifically for use

on ac and low voltage

dc applications.

Mechanical Life:

Maintained — 100,000 operations, minimum. Momentary — 25,000 operations, minimum.

To determine your Complete Catalog Number, you must start with the appropriate Base Circuit Number and add appropriate cOde Letters and/or Numbers as in the example below:

the

Circuit with Rocker in

BASE CIRCUIT

CODE LETTERS AND NUMBERS — ADD TO BASE CIRCUIT NUMBER

UP Position

CENTER Position

DOWN Position

Termination Type

Mounting

Frame

Bulb Voltage

Lamp

Wiring

Rocker

Style

Rocker Color

Lens Color

Poles and Throw

Rating

.250"

Spade Terminal

Solder Lugs

Screw Terminal

Voltage

Type

Color Code

Code

Type Code

Type Code

Color Code

Color Code

NON-ILLUMINATED

NON-ILLUMINATED

10A 250V ac

White Red Black

Non-Sealed

15A 125V ac

Black

N

N/A

N/A

N/A

N/A

Two Face

N/A

N/A

Sealed

15A

28V dc

ILLUMINATED

ILLUMINATED

White Red

Green Amber

No Lens

Blue

14V dc 18V dc 28V dc

125V O

Neon

250VO

Neon

10A 250V ac

Two Face

w/1 Lens

Dependent

on Circuit

ndependent of Circuit

3

White Red Black

Non-Sealed

15A 125V ac

Black

N

Two Face

w/2 Lenses ©

Sealed

2

4

15A 28V dc

2

•Momentary contact.

O 3A 8 250V ac, 6A 8 125V ac.

0 1/4 Hp 8 125-250V ac.

© Not available with lamp wired independent of circuit and provided with (2) lamps and (2) lens only (use only rocker styles 4 and 9). Note: All double throw circuits both 1 pole and 2 pole require

(2) lamps and (2) lens when lamp wired dependent on circuit. When lamp wired independent of circuit for 1PDT switches: device is supplied with 1 lamp and (2) lens (lamp centered in

open pole of base).

© Available on single pole versions only.
