EAO – Your Expert Partner for Human machine interfaces R.series vandal-resistant pushbuttons

Ω Insulation resistance: >1000 M Ω Dielectric strength: 2000 VAC Mechanical characteristics Environmental specifications Operating temperature Non-illuminated: –20 °C ... +55 °C Illuminated: –20 °C ... +70 °C Operating humidity 45 – 85% RH (no condensation) Approvals Conformity declaration RoHS Please note: EN/VDE and UL approvals for the operating voltages 110/250 V in preparation Mechanical lifetime 1 million cycles Actuating force 5.5 N Electrical characteristics Switching system Switch rating Non-illuminated 2 A / 48 VDC Illuminated 5 A / 250 VAC Electrical life (full load) Non-illuminated 16 mm: 40,000 cycles 24 VDC / 2 A 19 mm: 40,000 cycles 48 VDC / 2 A Illuminated 19 mm: 50,000 cycles 5 A / 250 VAC Switching element Contact resistance: ≤50 m Contact arrangement Non-illuminated (1 NO) Illuminated (1 NO / 1 NC) Contact function Momentary Contact material Silver alloy Terminals Non-illuminated: screw terminals Illuminated: solder terminals (2.8 x 0.5 mm, solder or plug-in terminal) Main features Vandal resistance: impact resistant to IK09, sealed to IP65 EAO introduces the R.series, a range of vandal-resistant pushbuttons that are designed to improve the durability and strength of control panels. These pushbuttons are protected to IK09 and IP65, which makes them ideal for use in exposed public areas or aggressive industrial environments. They are mounted in either 16 mm or 19 mm holes. The 19 mm versions are available with LED illumination, either an attractive “halo” ring or central dot. The halo effect creates a stylish, contemporary look that is also an effective way to focus the user’s attention on a primary function. Please note: the 16 mm versions are non-illuminated.
â–  â–  Long service life: one million operations
â–  Halo or dot illumination (19 mm only) Typical applications
â–  Access driver, security systems
â–  Exposed public areas: ticketing machines, vending machines, kiosks
â–  Industrial: machinery and factory equipment Dimensions Non-illuminated 16 mm / 19 mm dia. Illuminated 19 mm dia. Materials Button Non-illuminated: stainless steel gold brass nickel-plated brass Illuminated: stainless steel

www.eao.com/R_en
