22.5mm IP67 42V100mAIP65 3A250VAC (E-stop)

Condensed Catalogue - Complete Catalogue - 9307 Series 84

Choose one component from each of the coloured sections to assemble a complete switch. For other options or further information please contact your local sales office.

BLOCK LED ACCESSORIES

A

Emergency-stop switch Indicator element

Emergency-stop non illuminated,plug-in terminals,twist release,32mm diameter for 22.5mm mounting,foolproof to EN 60947-5-5 Emergency-stop non illuminated,ribbon cable, twist release,32mm diameter for 22.5mm mounting,foolproof to EN 60947-5-5 Indicator element,24VDC LED, plug-in terminals

Part No.Contact type Part No.Contact Type ColourPart No.Comment 84-5020.00201NC 84-5020.00401NC RedYellow Green BlueWhite 84-8002.2620Multi-chip LED 84-5040.00202NC 84-5040.00402NC 84-8002.4620Multi-chip LED 84-5030.00201NC/1NO 84-5030.00401NC/1NO 84-8002.5620Multi-chip LED 84-8001.6620Single-chip LED 84-8001.9620Single-chip LED For complete switch also order

A A

Switch element

A

Accessories

231

Switching element,24VDC LED,plug-in terminals,1NO Lens,plastic for flush mount,round indicator and pushbutton bodies Lens remover for flush mount,mounting tool and switch element remover

ColourPart No.Comment ColourPart No.Comment ImagePart No.Product description RedYellowGreenBlue White 84-8512.2620Multi-chip LED RedYellowGreenBlue Clear Black 84-7111.200 161-9730.0Lens remover for flush mount 84-8512.4620Multi-chip LED 84-7111.400 284-997Mounting tool 84-8512.5620Multi-chip LED 84-7111.500 384-998Switch element remover 84-8511.6620Single-chip LED 84-7111.600 84-8511.9620Single-chip LED 84-7111.700 84-8510.0020No LED- switching element only 84-7121.000Not for illumination For complete switch also order

59
