Series 14

22.5mm 30.5mm IP67 5A 250VAC

Choose one component from each of the coloured sections to assemble a complete switch.

For other options or further information please contact your local sales office.

LED

ACCESSORIES


(JP Selector switch		Selector lever 2 \| snap-ac		(g) Buzzer
Selector switch short 3 /"""N^a? lever 2 position, raised, *( a \ ^c-{*—i J snap-action \r		Selector lever 2 \| snap-ac	switch long 3 ^"^901 position, raised, *( a \ 4—i J tion ^c^\^* tt	* * A » Buzzer, plastic bezel, raised, 22.5mm mounting, 24VDC, IP65, 95dB ±8 at a distance of 0.1m
Drawing	Part No. Momentary/Maintained Contact type	Drawing	Part No. Momentary/Maintained Contact type	Part No. Product description
3	14-501.0252 Momentary 1NC/1NO	3	14-551.0252 Momentary 1NO/1NC	14-810.002 Black plastic
4	14-506.0252 Maintained 1NC/1NO	4	14-556.0252 Maintained 1NO/1NC	1 14-810.902 Chromium-plate







	For flush mount order bezel 704.955.1
For complete switch also order A		For complete switch also order A


mm Buzzer	0 LED

Buzzer, plastic bezel, flush mount, 30.5mm mounting, 24VDC, IP40, 95dB ±8 at a distance of 0.1m	LED, T5.5, single chip, 6 Volt and 12 Volt			LED, T5.5, single chip, 24 Volt and 28 Volt
Part No. Front finish	Colour	Part No.	Voltage	Colour	Part No.	Voltage
14-810.910 Black plastic	ORed	10-2106.3142	6VDC/15mA	ORed	10-2112.1062	24VAC/DC, 7/14mA
1 14-810.918 Chromium-plated	O Yellow	10-2106.3144	6VDC/15mA	O Yellow	10-2112.1064	24VAC/DC, 7/14mA
	O Green	10-2106.3145	6VDC/15mA	O Green	10-2112.1065	24VAC/DC, 7/14mA
	OBlue	10-2106.3146	6VDC/15mA	OBlue	10-2112.1066	24VAC/DC, 7/14mA
	O White	10-2106.3149	6VDC/15mA	O White	10-2112.1069	24VAC/DC, 7/14mA
	ORed	10-2109.1062	12VAC/DC,7/14mA	ORed	10-2113.1062	28VAC/DC, 7/14mA
	O Yellow	10-2109.1064	12VAC/DC,7/14mA	O Yellow	10-2113.1064	28VAC/DC, 7/14mA
	O Green	10-2109.1065	12VAC/DC,7/14mA	O Green	10-2113.1065	28VAC/DC, 7/14mA
	OBlue	10-2109.1066	12VAC/DC,7/14mA	OBlue	10-2113.1066	28VAC/DC, 7/14mA
	O White	10-2109.1069	12VAC/DC,7/14mA	O White	10-2113.1069	28VAC/DC, 7/14mA
