A105N 'Appello' Speech & Tone Alarm Sounder - E2S - #1

Text version of the page

E2S Datasheet 2.4.1 v10a Features: • Direct message storage on silicon: 16s of speech • Very high voice reproduction quality - mylar speaker • Message length: 1 x 16 seconds or 2 x 8 seconds. • Easy message creation with built in microphone. • Edits automatically to message length. • DC versions have reverse polarity diode protection. • Unit can be mounted using external lugs or internal BESA compatible fixing positions. • Duplicate cable terminations (in & out for daisy-chain installations). • Tropicalisation available on request. • Volume control & tone duration control. • Available with custom tone configurations and frequencies. Part codes: Version: Part code: 12V dc A105NAPPTDC12[x] 24V dc A105NAPPTDC24[x] 115V ac A105NAPPTAC115[x] 230V ac A105NAPPTAC230[x] [x] = Housing colour: G: Grey R: Red W: White The A105N Tone Appello is a voice alarm sounder capable of storing up to 16 seconds of user recordable speech. The sounder records, stores and plays back user defined messages stored directly to non-volatile memory without any intermediate analogue to digital conversion. Low current consumption and high sound output in a robust fire retardant IP66 housing ensure the A105N Tone Appello is suitable for all general signalling applications including fire, security and process control. A105N Appello Speech & Tone alarm sounder
