The BE 22 SK consists of an air motor,a gear box and a body.The design is compact as well as robust.BE 22 SK comes in a wide range
of speeds,and is available for lubrication-free operation.
● STURDY AND COMPACT DESIGN ● WIDE RANGE OF RPMs ● DIRECTED EXHAUST ● CHUCK ALTERNATIVES UP TO 20 MM ● IS AVAILABLE IN COUNTER CLOCKWISE ROTATION
Guidelines for choice of unit [,mm]
DRILLING UNITCAPACITY IN STEEL CAPACITY IN ALUMINIUM/BRASS CAPACITY IN WOOD/PLASTICS No of Spindles 1234 123 4 1234 BE 225 SKBE 228 SKBE 2211 SK
BE 2222 SK
BE 2236 SK
BE 2249 SKBE 22220 SK 8654 8554 12987 201197
LOW SPEEDHIGH SPEED 6444 10876 161197 6333 9765 14986 52.52.52 8665 12875 41.51.51.5 6554 10664 212987 3221198 4
Performance specifications at 6.3 Bar
Power0.25 kWMin.Center to Center SpacingSingle Spindle45 mmDouble-Spindle Head11 mmRun-out at spindle nose (max.)0.03 mmWorking pressure range67 BarAir consumption<0.3 Nm
3 /minSound level70 dB(A)
DRILLING UNIT SPEED (IDLE)[RPM] SPEED (AT MAX OUTPUT)[RPM] TORQUE (AT MAX OUTPUT) [NM] BE 225 SKBE 228 SK
BE 2211 SK
BE 2222 SKBE 2236 SKBE 2249 SK
BE 22220 SK 500 250 9.9800 400 6.01 100
LOW SPEEDHIGH SPEED 550 4.32 200 1 100 2.43 600 1 800 1.54 900 2 450 1.122 000 11 000 0.25 8
