AND HIGH SPEED GRINDER HFS100
Precision drilling/grinding unit with a basic design based on a patentedair-driven turbine motor.The drive unit is powered without intermediategears and features variable speed control up to 80 000 rpm.A special
high-speed precision bearing makes the drilling unit extremelyquiet with
a sound level of 67 dB (A).BE 11 / HFS 100 is designed for lubrication-free operation.
BE 11
HFS 100
● 80 000 RPM ● PRECISION UNIT FOR DRILLING,
DEBURRING ETC ● HIGHLY STABLE
BEARING SYSTEM ● LOW NOISE LEVEL (67 dB(A)) ● HFS 100:ALSO AVAILABLE AS HIGH SPEED GRINDER (HFS100),WHICH INCLUDES A HOSE SUITABLE FOR MANUAL HANDLING OF THE UNIT (SEE PICTURE).
Guidelines for choice of unit[,mm]
DRILLING UNITCAPACITY IN STEEL CAPACITY IN ALUMINIUM/BRASS CAPACITY IN WOOD/PLASTICS BE 11 1.534
Performance specifications at 6.3 bar
Power0.08 kWSpeed<80 000 rpm
Torque 0.02 NmMin.CC Spindle Spacing 54 mmRun-out at spindle nose (max.)0.007 mm
Working pressure range46.3 BarAir consumption <0.12 Nm
3 /minSound level67 dB(A) 6
