Dimensions [mm]
78 204642 You can download 2D CAD-drawings and 3D CAD-models on www.e2systems.com .
On www.e2system.com you can find more information as well as the same information as above in imperial units.When requesting a quote or ordering please state:
DRILLING UNITA [MM]B [MM]C [MM]D [MM]E [MM]WEIGHT[KG] BE 225 384 140 147 94.5 107 5.1BEF 225 519 200 177 154.5 167 7.1BE 228 384 140 147 94.5 107 5.1BEF 228 519 200 177 154.5 167 7.1BE 2211 384 140 147 94.5 107 5.1BEF 2211 519 200 177 154.5 167 7.1BE 2222 353 140 116 94.5 107 4.7BEF 2222 488 200 146 154.5 167 6.7BE 2236 353 140 116 94.5 107 4.7BEF 2236 488 200 146 154.5 167 6.7BE 2249 353 140 116 94.5 107 4.7BEF 2249 488 200 146 154.5 167 6.7BE 22150/22220 353 140 116 94.5 107 4.7BEF 22150 488 200 146 154.5 167 6.7
Necessary components Accessories
CHUCKS TYPE PAGE 5051 MULTI-SPINDLE HEADS TYPE PAGE 4246 Key chucks Adjustable heads Ø 0.5–6.5 mm (Standardchuck) VH04-,VH06- MBK 6V-series Ø 0.8–10.0 mm Collet chucks CONTROLSTYPE PAGE Ø 1.0–10.0 mm
Ø 3.0–20.0 mm Controls for BE 22/33-units
ElectricPneumatic56 COLLETS TYPE PAGE DA 200 51 Ø 1.0–10.0 mm DA 180 Ø 3.0–20.0 mm MOUNTINGSTYPE PAGE Mountings for the BE(FP) 22 LIMIT SWITCHESTYPE PAGE ElectricPneumatic56 Model,Chuck (collet size),Limit Switches and if it is to be used inLubrication-free operation.
Limit switch package canbe mounted on either side.
17
