The BE 33 SK consists of an air motor,a gear box and a body.The design is compact as well as robust.BE 33 SK comes in a wide range of speeds,and is available for lubrication-free
operation.
● STURDY AND COMPACT DESIGN ● WIDE RANGE OF RPMs ● DIRECTED EXHAUST ● CHUCK ALTERNATIVES UP TO 20 MM ● IS AVAILABLE IN COUNTER CLOCKWISE ROTATION
Guidelines for choice of unit [,mm]
DRILLING UNITCAPACITY IN STEEL CAPACITY IN ALUMINIUM/BRASS CAPACITY IN WOOD/PLASTICS No of Spindles 1234 123 4 1234 BE335SKBE 337SKBE 3313SK
BE 3326SK
BE 3333SK
BE 3360 SKBE 33210 SK 13766 13766 1610108 22121010
LOW SPEEDHIGH SPEED 10765 141088 20121010 9654 12986 1610109 6543 9766 131088 4433 7555 10865 2.51610109 426121010 5
Performance specifications at 6.3 Bar
Power0.36 kWMin.Center to Center SpacingSingle Spindle50 mm
Double-Spindle Head11 mmRun-out at spindle nose (max.)0.05 mmWorking pressure range67 BarAir consumption <0.5 Nm
3 /minSound level70 dB(A)
DRILLING UNIT SPEED (IDLE)[RPM] SPEED (AT MAX OUTPUT)[RPM] TORQUE (AT MAX OUTPUT) [NM] BE 335SK
BE 337SKBE 3313SK
BE 3326SK
BE 3333SK
BE 3360SKBE 33210SK 500 250 12.6700 350 10.41 300
LOW SPEEDHIGH SPEED 650 5.72 600 1 300 2.93 300 1 650 2.36 000 3 000 1.321 000 10 500 0.37 12
