BULLETIN NO. 2008-09-ET24 MODEL EJECTOR TRUCK ET-24 11.8 yd 3 – 9.0 m 3 capacity .. 24 ton – 22 metric tonne payload The DUX MODEL ET-24, 24 short ton (22 metric tonne) capacity compact profi le articulated four-wheel drive ejector truck is designed for the transport of ore, waste rock and backfi ll on level and steep ramps in areas with extremely low headings. FEATURES • High power to weight ratio assures fast tramming up steep ramps • Field proven Dana SOH powertrain • Fail-safe spring applied hydraulically released four-wheel POSISTOP brake system for long service life. • Large sized, heavy-duty oscillation roller bearing for minimum maintenance, a smooth ride and four-wheel ground contact on uneven terrain. • Frames designed and built to withstand high impact and torsional stress associated with mining or tunneling, even in sub-zero temperatures, covered by fi ve-year warranty. • Ruggedly built DUX ejector box made from high tensile abrasion resistant alloy steel consisting of main box with solid tubular front, reinforced bottom, formed sides, pusher plate arrangement activated by two fully protected, double acting telescopic hydraulic cylinders and a hydraulically operated swing down automatic tailgate. • Centralized service points and modular design allow for easy service access and fast component exchange • Excellent service and parts back-up worldwide OVERALL DIMENSIONS Length.......................................................30'-8" ...............9 350 mm Width ..........................................................7'-3" ............... 2 210 mm Height over ejector box sides......................7'-6" ...............2 285 mm Height over operator’s FOPS/ROPS cab .. 7'-11" ............... 2 415 mm TURNING RADIUS @ 43º TURNING ANGLE Inside .......................................................13'-11" ...............4 240 mm Outside .....................................................24'-0" ............... 7 315 mm EJECTOR BOX VOLUME* SAE struck .............................................. 9.6 yd3 .....................7.3 m3 Semi-heaped......................................... 10.7 yd3 .....................8.2 m3 SAE heaped...........................................11.8 yd3 .....................9.0 m3 *Other box sizes available on request WEIGHTS Payload............................................. 48,000 lbs ............... 21 773 kg Machine weight, approx. ................... 53,000 lbs ............... 24 041 kg GVW................................................101,000 lbs ............... 45 814 kg
