Type Measuring range mm Object height max. mm Lens Camera Max. workpiece weight on glass plate kg Length measurement uncertainty 1) DIN EN ISO 10360-2 VDI/VDE 2617 Dimensions mm PC workstation not included Weight kg Electrical supply VideoCAD S VideoCAD 1 VideoCAD 2 VideoCAD 3 X 48 X 80 X 144 X 225 Y 36 Y 60 Y 108 Y 168 other measuring ranges available upon request 60 Telecentric special lens 5 mega pixel b/w CCD matrix camera 20 E2 = (2.0+L/50 mm)ìm E2 = (4.0+L/50 mm)ìm E2 = (6.0+L/50 mm)ìm E2 = (10.0+L/50 mm)ìm Measuring length L in mm W 210 W 290 W 650 W 650 D 230 D 720 D 680 D 680 H 750 H 550 H 1800 H 1800 50 50 150 150 220-240VAC, 50-60Hz, 1kW 1) Prerequisites: Admissible ambient conditions 20 °C ± 1K, Temperature gradient th = 0,5 K/h, td = 4,0 K/d measured with a calibrated standard Technical Specifications of the VideoCAD Series Technical modifications reserved – 02.2011/AV/ODD Measurement and analysis software SAPHIR Efficient workflows are essential to successful business operations, and so is consistent cost optimisation. It is, therefore, not by coincidence that choosing the right machinery with the right software is a key component of any corporate streamlining process. Since “Schneider” is the German word for “tailor”, you can rightly conclude that SAPHIR is a truly “tailor-made” measuring software that leaves nothing to be desired: from “A” as in “axis alignment” to “Z” as in “zero-point administration” – SAPHIR is a valuable resource with invaluable features. For further information, please request our free “SAPHIR” brochure. Dr. Heinrich Schneider Messtechnik GmbH · Rotlay-Mühle · 55545 Bad Kreuznach · Germany Tel. +49 671 291 02 · Fax +49 671 291 200 · info@dr-schneider.de · www.dr-schneider.de
