EratoTompa Deimos Kaliope Quantico AirMedic 2006/2007 Air Handling Units >

2. Our markings 3. Partners of DOSPEL Professional4. Certificates7. Our machine park9. Functions of Various Components Fitted In DOSPEL Professional Air Handling Units 10. Operational range of units 12. Arrangement possibilities13. Types of air handling units14. Configuration of inlets and outlets 15. Deimos suspended air handling unit 16. Erato Standard Air Handling Units 16. Tampa Roof Air Handling Units 17. Other types 18. Construction20. Enclosure21. Ventilator22. Filter 23. Heaters24. Coolers25. Silencer 26. Automation and control 28. BMS28. Alternative Control Unit29. Typical...

DOSPEL Co. Ltd. is one of the largest manufacturers of ventilation and air-conditioning equipment and systems. DOSPEL Professional, a member of the DOSPEL Group, specialises in industrial ventilation and air-conditioning systems.Over thirty years' experience, a highly-qualified team of engineers and high quality products make DOSPEL a reliable partner.Many years leadership in domestic market and exports to over 50 foreign markets confirm our superiority in highly advanced technology introduced in our products at competitively low price.The innovative technology of our equipment and...

Fan FiltersHeater > PanelfilterPreliminary Bag filterSecondary Bag filter Water heater Electric Cooler > Water cooler F-cooler Mixing chamberCross flow Heat exchangerRotary Heat exchangerClosed-loop Heat exchangerSilencerDamperFlexible connection >

We cooperate with renowned institutions The Chemical Company 3 >

TUV > EN-1886 EN-13053 TUV > Since its onset, DOSPEL Professional has been highly concentrating on providing proper and professional service to its customers. Taking into consideration of client's interest, Company implemented the ISO Quality Management System and was awarded all necessary certificates relating to quality and safety.Hygienic attest - guarantees perfect quality of all materials used for producing of ventilation and air-conditioning equipment and systems.CE - is a declaration of conformity of equipment produced by DOSPEL with the requirements of:- PN-EN 1886 Standard- PN-EN...

Shearing is carried out by an Amada Vipros 368 King hydraulic revolving press with a 58 tool head. The machine handles metal sheets of up to 3000 x 1500 mm and 3.2mm thick. The press has a brushing bench with additional feeding and collection system. HFE 100.3 and HF-50.12 bending brakes are high-quality devices for bending sheets equipped with digital measurement and angle correction. Two independent hydraulic servo drive the units, and intelligent control ensures a smooth and repeatable bending process. The maximum bending length for HFE 100.3 is 3090mm and for HF-50.12 it is 1250mm. >

A single-head High-Tech saw is used for the precise cutting of aluminium profiles. The machine is equipped with a compatible profile feeder handling profiles up to 6000mm in length. It is possible to digitally set the piece length up to 0.01mm and to regulate the cutting angle. A modern plasma contour band cutter NESSAP 1600 allows for cutting sheets 0.8-20mm thick, and handles single sheets of up to 1500 x 3000mm. The device serves cutting mild steel, stainless steel and aluminium. Pneumatic driven machine serves to spot-join sheets by clamping - in accordance with DIN 8593. Press-joining...

Supply (N) > Exhaust (W) Supply-Exhaust (NW)with Mixing Chamber Supply-Exhaust (NW)with Rotary Heat Exchanger (O) Supply-Exhaust (NW)with Glycol Heat Exchanger (G) Supply-Exhaust (NW)with Cross-Flow Heat Exchanger (X) > The side of execution shows the location of the connectors of the exchangers and the location of the drainage of condensate. In the case of supply and exhaust units, the designation in the unit code is used both for the supply and ventilating part. >

These Air Handling Units are intended for use inside buildings, i.e. in plant rooms, basements, etc. The casings are made of sandwich panels filled with rigid polyurethane foam or mineral wool between two sheets of metal. Panel thickness depends on the application and the weather conditions. Sandwich panels give excellent thermal protection and meet rigorous acoustic requirements. Roof units are equipped with a little roof, air inlets and dischargers. The roof protects against precipitation and its profile prevents water accumulation and leaks. The design of the air inlet and air...

epoxide or stainless sheet -exchangers in epoxide version. Automatics used in such units provides temperature and humidity control. Units designed for hospital buildings conform with all criteria regarding cleanliness, leak tightness and reliability applied to such equipment.The design of AirMedic enables users to clean them frequently. Stainless steel enclosure and The automatics of units designed for garage ventilation provides the efficiency control depending on CO concentration in the air. It makes it also possible to program the function of garage ventilation. Taking into account their...

Unit enclosures are made from ply-boards filled with polyurethane foam or mineral wool coated on both sides with galvanised iron sheets, epoxide sheets and stainless sheet. During production, sheet surfaces are covered with foil protecting them against damage and dirt. Board thickness is 18-35 mm and depends on their design. Ply-boards provide excellent thermal and acoustic insulation. > the flow at the unit start-up. In recirculation systems, the dampers function is to regulate the air flow and protect the cross-flow heat exchanger against frosting. Damper opening can be set manually or by...

The frame of the standard and rooftop Air Handling Unit is made of aluminium profiles fixed with polyamide corners for compactness and stability. A steel mounting frame gives the structure an extra rigidity. Excellent tightness of the casing is a result of double door sealing: on the outside surface of the profile and on the inside surface with a gasket. >
