Knurling Tools - 1

"The Knurling Tool Specialists For C.N.C. and Manual Lathes" ® 1998 CATALOG Knurling Tool Catalog United States of America Price $14.50 International

Open the catalog to page 1
Knurling Tools - 2

DORIAN TOOL INTERNATIONAL Riccardo A. Giannetti Henry Rogers Southwest Product District Manager Quality Control Enrico R. Giannetti President Dear Customer, Nancy Bucek Inside Sales Since the introduction of our original Quadra Index Tool Post in 1982 and Indexable Tool Catalog in 1995, Dorian Tool International has expanded its product line with some of the most advanced tools in the industry. The success of our business has never undermined the original commitment made to our customers in supporting productivity, quality, and cost reduction. These goals have been achieved through delivery...

Open the catalog to page 2
Knurling Tools - 3

® International Dorian Service Network « USA Dorian Tool Corporate Office and Manufacturing Plant 615 County Road 219 East Bernard, TX 77435 (800) 627-0266 (979) 282-2861 FAX (979) 282-2951 E-MAIL sales@doriantool.com WEB SITE www.doriantool.com Contact Dorian Tool for your closest international agent. DORIAN TOOL INT'L 615 COUNTY ROAD 219 EAST BERNARD, TX 77435 1-800-627-0266 979-282-2861 FAX: 979-282-2951 B-II

Open the catalog to page 3
Knurling Tools - 4

® United States Dorian Service Network « USA (800) 627-0266 Dorian Tool Corporate (979) 282-2861 Office and Manufacturing Plant FAX (979) 282-2951 615 County Road 219 E-MAIL sales@doriantool.com East Bernard, TX 77435 WEB SITE www.doriantool.com 2 3 Southwest Product District Manager 615 County Road 219 East Bernard, TX 77435 Riccardo A. Giannetti (979) 282-2861 FAX (979) 282-2951 Nick Grad (800) 551-1081 (248) 478-0666 FAX (248) 478-0826 Professional Tech. 985 E. 4500 S. Salt Lake City, UT 84117 Clyde Cottrell (801) 269-1055 FAX (801) 268-0511 3271 S. Magnolia St. Denver, CO 80224 Greg...

Open the catalog to page 4
Knurling Tools - 5

® Graphic Index Three Swivel Head Knurling Tool Pages B-9 CNC Modular Knurling Tool Pages B-1 - B-6 107ST Straight Cutting Knurling Tool Pages B-7 CNC109 Side Mount Straddle Knurling Tool Pages B-7 Single Wheel Fixed Knurling Tool Page B-9 Single Wheel Fixed Knurling Tool Page B-10 Heavy Duty Single Wheel Fixed Knurling Tool Page B-10 Shoulder Fixed Knurling Tool Page B-11 Self-Centering Knurling Tool Page B-12 Shoulder Self-Centering Knurling Tool Page B-12 Heavy Duty Fixed Knurling Tool Page B-13 Heavy Duty Self-Centering Knurling Tool Page B-13 Milling Machine Knurling Tool Page B-14...

Open the catalog to page 5
Knurling Tools - 6

Quote Number ® Knurling Tool Applications Purchase Order Number Need help, fill in the required information shown below and fax to: (409) 282-2951 Company ______________________________________________ Name _______________________________________________ Address _______________________________________________ ( ) Phone _______________________________________________ City __________________________________________________ ( ) Fax _________________________________________________ State ________________________ Zip _____________________ Where did you hear of our products: ____________________...

Open the catalog to page 6
Knurling Tools - 7

® Knurling Applications Consult the tables below for the best tool for your application. Best SCK SSCK Good Fair Not Recommended CNC-6 SSCK SFKT SCK Good Fair Not Recommended CNC-7, SCNC-7, & KT109C KTW109 CNC-1 & SCNC-1 SCK Best Good Fair Not Recommended KTW109 CNC-1 & SCNC-1 SSCK KT109C Best Internal Diamond or Straight To a Shoulder KTW109 & KT109C Best Small Dia. Diamond To a Shoulder Not Recommended KTW109 Small Dia. Diamond Shoulderless Fair Best Diamond To a Shoulder Good CNC-1/2/3 Diamond Shoulderless Good Fair Not Recommended Best KTW109 & KT109C SCK SSCK Good Fair Not Recommended...

Open the catalog to page 7
Knurling Tools - 8

® Discover The Mystery Of Knurling Applications Speed and Feeds Knurling has a wide variety of applications in day to day use. It is most commonly used for decorative purposes and for serrating surfaces where components are locked or keyed together in unit assemblies. The term "knurling" designates both the process and the knurled portion of the work. Knurling is obtained by displacement of the material when the knurl is pressed against the surface of a rotating work blank. A knurled tooth is "V" shaped. Knurling tools are used for producing STRAIGHT, DIAGONAL, OR DIAMOND shapes, having...

Open the catalog to page 8
Knurling Tools - 9

® General Knurling Information Knurling Pattern STRAIGHT KNURLING RIGHT-HAND KNURLING Tooth Form LEFT-HAND KNURLING DIAMOND KNURL Male or Female Straight Knurling A knurled tooth is V-shaped and the depth of the tooth is less than the depth of a theoretical V-form. The tooth has a rounded root and crest. The relationship between the actual depth of tooth to the theoretical V varies with the pitch of the teeth. On finer pitches, the tooth is a smaller proportion of the theoretical V-depth than coarser pitches. Also, female diamond patterns have shallower tooth depth than male diamond...

Open the catalog to page 9
Knurling Tools - 10

® Circular Knurling Information TPI and Circular Pitch Calculations General Purpose Knurling The formula for finding the Transverse Teeth Per Inch (TPIt), if the Normal Teeth Per Inch (TPIn) is known, is shown below. For general purpose knurling, only limited dimensions are necessary. • TPI (Teeth Per Inch) • Work Blank Diameter • Knurled Diameter TPIt=TPIn x Cos 30° (.86603) The formula for finding the Transverse Circular Pitch (Pt), if the Circular Pitch (P) is known, is shown below. P Pt= Cos 30° (.86603) TPI and Circular Pitch Examples Find the Transverse Pitch if the Normal Pitch is 20...

Open the catalog to page 10
Knurling Tools - 11

® Circular Knurling Information Diagonal & Diamond Knurl Tooth & Pitch Calculations TPIt= Nw 3.1416 x Dw or TPIn x cos Ø Work Blank Diameters Nw TPIt TPIn= or cos Ø 3.1416 x Dw x cos Ø Nw=3.1416 x D w x TPIt or 3.1416 x Dw x TPIn x cos Ø The diameter of the blank has a definite relation to the proper tracking of the knurl on its original contact with the work. The circumference of the work blank should be an approximate multiple of the circular pitch of straight knurls and the transverse circular pitch of diagonal knurls. With improper blank diameters, the teeth of the knurl as they...

Open the catalog to page 11
