MOISTURE-IN-ÛIL INSTRUMENTS (S) (2§ MOISTURE-IN-OIL INSTRUMENTS The DOMINO is an accurate, simple, robust and versatile instrument offered by Doble Engineering. The DOMINO, Doble's Moisture-in-Oil instrument, measures just that: moisture in oil in terms of ppm and relative saturation plus the added benefit of temperature. It is an instrument that provides for the continuous reliable measurement of the water content of electrical insulating liquids and other types of oils.
Introduction: Features: Why Measure Moisture in Oil? The determination of moisture in insulating liquids is an essential part of any compre-hensive maintenance or diagnostic program. Water is extremely detrimental to most oil filled systems and especially transformers and other liquid-filled electric apparatus. Knowing the water condition in real time is the best way to guard against harmful conditions that may exist or present themselves.
• Instantaneous Results- no waiting...the
DOMINO provides continuous results in parts per million (ppm), relative saturation and temperature on a single easy to read display and records the values in real time.
• An effective Monitor- continuously
monitors oil reconditioning in systems as small as a single filter cartridge to as large as a mobile or stationary processing plant. Helps in determining filter changeout, process efficiency, and determination of when to terminate the processing effort. Readout is directly in ppm—no need for messy charts and conversions. •
Simple to use- eliminates all harmful chemicals and laboratory systemic errors associated with Karl Fischer titrations, delicate Karl Fischer titration devices, sampling error, and contamination from ambient humidity. •
QuickResponse - In flowing oil at a velocity of 4 liters per minute or more (1 gallon/minute), the time for 100% response is 30 seconds or less. This means you can perform your job quicker and more accurately. •
Bsy installation- the probe installs directly in the flowing oil up to 2271 liters per minute (600 gpm). As for the transmitter, just plug it in...it will start to measure and display immediately.
(9^ (2§ In 1999, Doble introduced the first
DOMINO that became an instant success. Its enthusiastic acceptance in the industry has placed it as another respected, superior quality instrument provided by Doble Engineering. The success was due in main part to the variety of applications that it could be used. The variety of application uses, along with its robustness and Doble's technical expertise have made the
DOMINO an industry standard. In 2007, Doble introduced the second generation of
DOMINO and has been very well received by the industry. The new generation of
DOMINO brings a progression from just a basic sensor to an instrument with many enhancements and added features from the first generation.
