www. STANDARD LINEAR AND LOGIC PRODUCTS

designers with the most advantageous combination of efficiency, functionality, and package size. Diodes Incorporated offers a portfolio of devices that meet the requirements of a wide range of electronic applications by addressing these competing design criteria to produce elegant and practical solutions. The breadth of Diodes’ standard linear portfolio provides designers with cost-effective industry standard replacements to high performance devices for the most demanding industrial and automotive applications. Portable consumer Communications Computer Automotive Diodes’ Standard Linear extends...

Standard Linear Operational Amplifiers 4 Comparators 5 Current Monitors Programmable Voltage Gain 6 Current Mirror 6 Current Monitors Fixed Gain 7 Shunt Regulators 8 Shunt References 9 Reset Generators 10 Standard Logic Single Gate Low Voltage CMOS 11

Collector 15kÙ AP331A 2 36 0.4 4 70 150 0 V+ -1.5 - Open Collector 200 @ 15kÙ 16 1 0 to +70 AP393 2 36 0.4 1 5 25 0 V+ -2 - Open Collector 200 @ 15kÙ 16 2 0 to +70 AP393A 2 36 0.4 4 70 150 0 V+ -1.5 - Open Collector 200 @15kÙ 16 2 0 to +70 APX393 2.5 5.5 0.15 1.7 2 25 0.2 V+ -0.2 X Open Drain 50 @ 5.1kÙ 60 2 -40 to + APX339 2.5 5.5 0.24 1.7 2 25 0.2 V+ -0.2 X Open Drain 50 @ 5.1kÙ 60 4 -40 to + Product benefits THE DIODES ADVANTAGE Industry standard comparators for everyday applications. Pin-pin compatible with LMV393/339 Provides a low cost solution for 3V and 5V systems. Pin-pin compatible...

Page 6 ZXCT1009 Micro-Power High Side Current Monitor for portable equipment - - 2.5 20 VS- -1 2.5 - 2.5 4 10 2 -40 +85 ZXCT1010 Micro-Power High-side Current Monitor with improved offset - - 2.5 20 VS- -1 2.5 - 2.5 3.5 10 2 -40 +85 ZXCT1011 Micro-Power High-side Current Monitor with improved Temperature drift 2.5 20 VB VB VS- -1 2.5 - 2.5 4 10 1.5 -40 +125 ZXCT1012 ZXCT1010 with low profile package - - 2.5 20 VS- -1 2.5 - 2.5 3.5 10 2 -40 +85 ZXCT1020 Low offset Current Monitor 2.7 20 VB VB VS- -1 1.5 - 2 25 Prog 3 -40 +125 ZXCT1050 Input range includes 0V with separate VCC pin 2.7 20 0 VCC-2...

ZXCT1022 20V improved accuracy - - 2.5 20 VS- -1 0.18 15k 3 25 100 1 -40 to +85 ZXCT1023 Voltage Output - - 2.5 20 VS- -1 0.38 15k 3 3.5 25 1 -40 to +85 ZXCT1030 Voltage Output with Internal reference and comparator 2.2 20 2.2 VCC VS- -1 0.5 1.5k 3 270 10 6 -40 to +85 ZXCT1032 High-side inrush current limit controller - - 9.5 21 VS- -1 0.25 - - 1600 10 - -40 to +85 ZXCT1041 Bi-directional voltage output with flag - - 2.7 20 VS- -1 ±0.8 15k 3 35 10 0.3 -40 to +85 ZXCT1051 Input range includes 0V with separate VCC pin 2.5 20 0 VCC -2 VCC -2 0.3 3.75k 3 50 10 2 -40 to +125 ZXCT1080 AEC-Q100 High...

Page 8 TLV431 1.24 0.5, 1 18 15 100 50 0.4 -40 to +125 X ZR431L 1.24 1, 2.5 10 - 100 55 2 -40 to +85 - AP431 2.495 0.5, 1 36 250 190 30 0.5 -20 to +85 - TL431 2.495 0.5, 1 36 100 400 50 0.5 -40 to +125 - ZHT431 2.5 1, 2 20 150 50 55 0.75 -55 to +125 - ZR431 2.5 0.5, 1, 2 20 100 50 55 0.75 -40 to +85 - ZTL431 2.5 0.5, 1 20 100 400 50 0.5 -40 to +125 X ZTL432 2.5 0.5, 1 20 100 400 50 0.5 -40 to +125 X Product benefits THE DIODES ADVANTAGE Diodes’ shunt regulators provide cost-effective solutions consumer, power supply, industrial, and automotive applications. Wide temperature ranges, some to -40...

Page 10 2.25 2.63 2.93 3.08 4.00 4.38 4.63 APX809 1 5.5 20 200 - - Y - - - - - PP -40 APX810 1 5.5 20 200 - Y - - - - - - PP -40 APX811 1 5.5 20 200 - - Y Y - - - - PP -40 APX812 1 5.5 20 200 - Y - Y - - - - PP -40 APX823 1 5.5 25 200 1.6 - Y Y Y - - - PP -40 APX824 1 5.5 25 200 1.6 Y Y - Y - - - PP -40 APX825A 1 5.5 25 200 1.6 Y Y Y Y - - - PP -40 AP1701 1 5.5 20 200 - - Y - - - - - PP -40 AP1702 1 5.5 20 200 - Y - - - - - - PP -40 AP1703 1 5.5 20 200 - - Y - - - - - PP -40 AP1704 1 5.5 20 200 - Y - - - - - - PP -40 ZM33164-3 2.68 1 10 190 0 - - Y - - - - - OC -40 ZSM560 4.6 1 6.5 200 0 - -...
