The best Analog ICs provide circuit designers with the most advantageous combination of efficiency, functionality and package size. Diodes Incorporated’s LED lighting solutions are not only recognized for their high efficiency and simplicity, but also for their flexibility and versatility. They are well suited to tackle a wide range of applications: General lighting Signage and display Portable lighting Automotive Signals Its global footprint includes sales offices in 5 countries and manufacturing locations in China, Europe and the USA. A focus on product innovation, cost reduction, acquisitions...

Medium Voltage DC-DC LED Drivers 4 Medium Voltage Applications 5-7 General Illumination MR16 LED Lamp Solution 5 LED Lamp Solution for Refrigerators 5 LED Lamp Solution for Street Lights 6 LED Lamp LCD Projector 6 Automotive Lighting Door Lighting 7 Daytime Running Lights 7 Low Voltage DC-DC LED Drivers 8 Low Voltage Applications 9-10 Portable Lighting 2-cell Flashlight 9 Portable LED Projector 9 Signage and Display Single Cell Emergency Lighting 10 General Illumination Simple Solar Exterior Lights 10 Linear LED Drivers 11 Backlighting ICs and Bias Generators 12 LED Backlight Drivers 12 LCD and...

Page 4 ZXLD1374 X X X 6.5 60 60 1.5 2 1000 97 -40 to 125 225 ZXLD1366 X 6 60 60 1 3 500 95 -40 to 125 200 ZXLD1362 X 6 60 60 1 5 1000 95 -40 to 125 100 AP8802H X 8 60 60 1 5 500 92 -40 to 105 200 ZXLD1356 X 6 60 60 0.55 3 1000 97 -40 to 125 200 AP8802 X 8 48 48 1 8 500 92 -40 to 105 200 AP8801 X 8 48 48 0.5 7 500 92 -40 to 105 200 AL8805 X 6 30 30 1 5 1000 98 -40 to 125 100 ZXLD1360 X 7 30 30 1 5 1000 95 -40 to 125 100 ZXLD1350 X 7 30 30 0.35 5 1000 95 -40 to 105 100 ZXLD1352 X 7 30 30 0.35 5 1000 97 -40 to 105 100 AP8800 X 8 28 28 0.35 7 600 92 -40 to 85 100 Product Benefits THE DIODES ADVANTAGE...

AL8805 Benefits THE DIODES ADVANTAGE LED Lamp Solution for Refrigerators AP8802H Benefits THE DIODES ADVANTAGE The AP8802H provides a simple cost effective solution commercial refrigeration applications Operating voltage range up to 60V and down to - Up to 15 LEDs can be connected in series; higher power delivered without reduction in lumens at low temperature LED current can be up to 1A Drives both 1W and 3W LED systems Up to 500kHz switching frequency Small, cost-effective inductor and capacitor can be 5% initial average LED current accuracy Meets accuracy requirements of most lighting applications...

Page 6 ZXLD1366 Benefits THE DIODES ADVANTAGE The ZXLD1366EN8 provides a simple cost-effective streetlight and high bay lighting applications Operating voltage range up to 60V and 125ºC Up to 15 LEDs can be connected in series such power can be delivered without reduction in lumens 2.5% initial average LED current accuracy Meets accuracy requirement of most lighting applications improves inter-channel matching Supports up to 1A LED current Good match for 3W LED systems Low thermal impedance exposed pad SO-8EP Reduces junction temperature for increased long- Many high power lamps utilize multiple...

ZXLD1362ET5 Benefits THE DIODES ADVANTAGE Door safety lamps usually use just 1 high brightness LED so a simple buck converter is typically used. The lamp operates directly off the battery, requiring the driver to withstand load dump as well as meeting AEC-Q100 automotive quality requirements. The ZXLD1362 is qualified to AEC-Q100 grade 1. Its 1A capability allows it to drive 3W LEDs while the device's 60V operating voltage withstands most load dump conditions. ZXLD1362ET5 delivers a simple, small footprint solution automotive safety lighting 60V 1A LED drive capability Drives multiple 3W and...

Page 8 ZXSC300 Boost controller 0.8 8 Ext BJT Ext BJT - 94 -40 to 85 ZXSC400 Boost controller 1.8 10 Ext BJT Ext BJT - 94 -40 to 85 ZXLD1320 Buck driver 5 20 20V 1.5 600 85 -40 to 85 ZXLD1321 Boost driver 1.2 12 20V 1 600 85 -40 to 85 ZXLD1322 Buck-boost driver 2.5 15 20V 0.7 600 85 -40 to 85 ZXLD381 Boost driver 0.9 2.2 20V 0.320 350 85 -40 to 85 ZXLD383 Boost driver 0.9 3.3 20V 0.050 330 85 -40 to 85 ZXSC380 Boost driver 0.8 6 20V 0.080 160 80 -40 to 85 Product Benefits Simple low voltage LED drivers capable of operating from Boost controllers External transistor sets maximum LED current and...

ZXLD1320 Benefits Simple small footprint solution for Li-Ion powered 4W portable LED projectors 5 ~ 20V input voltage range Operates from 2 ~ 3 Li-Ion cells 1.5A output current Drives 4W LEDs High efficiency Buck LED driver Drives one 4W LED from one Li-Ion cell or two 4W LEDs two Li-Ion cells High power dissipation DFN4030-14 package Maintains high LED drive at higher ambient temperatures THE DIODES ADVANTAGE ZXSC310 Benefits THE DIODES ADVANTAGE R1 C2 R3 R2 R1 Exposed Tab ZXLD1320 M_LOAD COLLECTOR1 COLLECTOR2 POK VIN VREF TADJ ADJ BIAS CFB ISENSE EMITTER1 EMITTER2 C1 Due to the cost-sensitive...

ZXLD383 VCC VOUT NC ENA GND Solar Cell Array NIMH 1.2V 1 2 3 4 5 Page 10 ZXLD1321 Benefits THE DIODES ADVANTAGE Small footprint solution for safety-critical applications 1.2 ~ 12V input voltage range Operate from a single rechargeable cell 1A load current Drives 3W LEDs Boost topology Drives multiple 3W LEDs from one rechargeable High power dissipation DFN4030-14 package Maintains high LED drive at higher ambient temperatures Back Contact C1 R2 R1 Low Voltage Applications: General Illumination Emergency lighting applications require long run times from rechargeable batteries. The ZXLD1321 boost...

THE DIODES ADVANTAGE The DLD101 linear constant current driver is rated up The LED current is programmed with one external resistor, a low cost, space saving LED drive solution. Small footprint 3mm x 3mm DFN package Saves board space Low thermal impedance DFN package Higher power dissipation than SOT23 form factor 1A, 100V MOSFET as LED driver Drives multiple 3W LEDs giving increased light intensity without bias current issues of BJT pass elements Incorporates bias resistors and MOSFETs into package Provides simple, versatile small footprint Linear LED Current set with one external resistor Lower...
