Precision guide- Metric - 1

Precision Linear Motion Components & Accessories Product Guide Metric Version

Open the catalog to page 1
Precision guide- Metric - 2

Our Mission Del-Tron Precision was founded in order to serve the needs of automated equipment manufacturers for innovative, high quality and reasonably priced anti-friction linear bearings. Our Company The originator of the sub miniature ball bearing slide assembly; Del-Tron Precision Inc. began operations in 1974 supplying original equipment manufacturers with the world's first commercially available sub miniature ball slide, model D-1. Since then, thousands of Del-Tron® slides have been incorporated into automated equipment throughout the world. Manufacturers of medical analyzing and...

Open the catalog to page 2
Precision guide- Metric - 3

Selection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P 4 Ball Slide Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P 7 Anti-Creep Ball Slide Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P 10 Non-Magnetic Ball Slide Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . .P 13 Crossed Roller Slide Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P 16 Precision Series (Ball & Crossed Roller Slides) . . . . . . . . . . . . . . . . . . .P 19...

Open the catalog to page 3
Precision guide- Metric - 4

Selection Guide BALL SLIDES SERIES ANTI-CREEP BALL SLIDE ASSEMBLIES SERIES NON-MAGNETIC BALL SLIDES SERIES CROSSED ROLLER SLIDES SERIES PRECISION BALL SLIDE SERIES SERIES PRECISION CROSSED ROLLER SLIDE SERIES SERIES HIGH PRECISION SERIES BALL SLIDES (LOW PROFILE & FLANGE BASE) SERIES

Open the catalog to page 4
Precision guide- Metric - 5

Selection Guide HIGH PRECISION SERIES CROSSED ROLLER SLIDES (LOW PROFILE & FLANGE BASE) SERIES BALL SLIDE POSITIONING STAGES (MICROMETER DRIVEN) Available in X, XY, and XYZ configurations. SERIES WORK SURFACE 101PMM-3206-PMM 1.8 - 27 (11 MODELS, X and XY ONLY, no micrometers) CROSSED ROLLER POSITIONING STAGES (MICROMETER DRIVEN) Available in X, XY, and XYZ configurations. SERIES WORK SURFACE R101PMM-R3204PMM 10 - 73 (11 MODELS, X and XY ONLY, no micrometers)

Open the catalog to page 5
Precision guide- Metric - 6

Selection Guide LOW PROFILE CROSSED ROLLER TABLES SERIES LPTA-1025-3205 23 - 375 (21 MODELS) Stainless steel available. CROSSED ROLLER RAIL SETS SERIES MINI NB1 NB2-NB6 (49 MODELS) Stainless steel available. ANTI-CREEP CROSSED ROLLER RAIL SETS SERIES NB2-AC / NB6-AC CROSSED ROLLER SLIDE TABLES (ALUMINUM) SERIES MINI NBT-1AM NBT-2AM-NBT-6AM (72 MODELS) Stainless steel available. ANTI-CREEP CROSSED ROLLER SLIDE TABLES (ALUMINUM) SERIES CROSSED ROLLER SLIDE TABLES (STEEL) SERIES BALL SLIDE GUIDES SERIES

Open the catalog to page 6
Precision guide- Metric - 7

Ball Slides 6 Reasons to choose Del-Tron® Ball Slides Del-Tron ® Ball Slides Load Ratings and Life Estimates The rated load capacity of Del-Tron® ball slides may be a mass load on a horizontal slide,or a force load normal to the mounting surface in any position. The rated load must be centered and distributed over the slide, and the base must be fully supported on a flat mounting surface so that the ball slide does not act as a beam subject to concentrated or distributed bending forces. Loads supported by protruding arms reduce accuracy and load capacity by acting as levers or ratio arms,...

Open the catalog to page 7
Precision guide- Metric - 8

Ball Slide Assemblies moment load ratings + load / life formulas. pg.91 * Minimum Centered around Mean Position CARRIAGE HOLE SPACING BASE DIMENSIONS HOLE HEIGHT WIDTH SPACING H F G SERIES CA CARRIAGE M2 4 HOLES (I) THREAD BASE HOLE d M2 THREAD BASE HOLE D1 BASE HOLE h COUNTER BORE SCREW SIZE

Open the catalog to page 8
Precision guide- Metric - 9

Straight Line Accuracy .013mm/25mm of travel Coefficient of Friction 0.003 typical Construction Aluminum carriage and base, hardened steel shafts and balls, mild steel end caps. Finish Clear anodize standard Black anodize available at no extra cost. moment load ratings + load / life formulas. pg.91 *Minimum Centered around Mean Position LOAD CAPACITY TRAVEL (kg) CARRIAGE HOLE SPACING

Open the catalog to page 9
Precision guide- Metric - 10

Anti-Creep Linear Slides 6 Reasons to choose Del-Tron® Anti-Creep ™ Ball Slides 1. Ideal for vertical applications. 2. Increased life with overhanging loads. 3. Positive internal stops. 4. Low friction, straight line design. 5. Factory preload controls side play and backlash. 6. .013mm/25m″ straight line accuracy. Del-Tron ® Anti-Creep ™ Slides In certain applications, uneven loads, improper preload, vertical mounting, or offset forces may cause the ball retainers to become misaligned relative to each other. The misalignment (“creep”) can ultimately cause a reduction in overall travel, the...

Open the catalog to page 10
Precision guide- Metric - 11

Anti-Creep Linear Slides moment load ratings + load / life formulas. pg.91 * Minimum Centered around Mean Position CARRIAGE HOLE SPACING BASE DIMENSIONS HOLE HEIGHT WIDTH SPACING H F G SERIES CA CARRIAGE M2 4 HOLES (I) THREAD BASE HOLE d M2 THREAD BASE HOLE D1 BASE HOLE h COUNTER BORE SCREW SIZE

Open the catalog to page 11
Precision guide- Metric - 12

Straight Line Accuracy 0.13mm/25mm of travel Coefficient of Friction 0.003 typical Construction Aluminum carriage and base, hardened steel shafts and balls, mild steel end caps. Finish Clear anodize standard black anodize available at no extra cost. moment load ratings + load / life formulas. pg.91 *Minimum Centered around Mean Position LOAD CAPACITY TRAVEL* (kg) CARRIAGE HOLE SPACING

Open the catalog to page 12
Precision guide- Metric - 13

Non-Magnetic Linear Slides 6 Reasons to choose Del-Tron® Non-Magnetic Ball Slides Del-Tron ® Ball Slides Load Ratings and Life Estimates The rated load capacity of Del-Tron ball slides may be a mass load on a horizontal slide,or a force load normal to the mounting surface in any position. The rated load must be centered and distributed over the slide, and the base must be fully supported on a flat mounting surface so that the ball slide does not act as a beam subject to concentrated or distributed bending forces. Loads supported by protruding arms reduce accuracy and load capacity by acting...

Open the catalog to page 13
Precision guide- Metric - 14

Non-Magnetic Linear Ball Slides * Minimum Centered around Mean Position LOAD CAPACITY TRAVEL* (kg) CARRIAGE HOLE SPACING BASE DIMENSIONS HOLE HEIGHT WIDTH SPACING H F G SERIES CARRIAGE 4 HOLES (I) BASE HOLE d BASE HOLE D1 BASE HOLE h COUNTER BORE SCREW SIZE

Open the catalog to page 14
