DE-STA-CO Locating Pin Clamps 82P Series Locating Pin Clamp Features and Benefits Introduction DE-STA-CO's Model 82P clamps are designed to locate and clamp sheet metal in welding and material transfer applications. The enclosed aluminum body houses a full toggling mechanism that secures the part in place even when air is removed from the tool. These units are very powerful as a result of the mechanical advantage of the toggle mechanism so large clinders are not needed. 82P Locating Pin Clamps can be used on a stationary tool as well as a moving pallet system and are available with either an...

DE-STA-CO Locating Pin Clamps 82P Series Locating Pin Clamp Opration Principe DE-STA-CO's 82P Locating Pin Clamps are made using a fully enclosed body with hardened steel wear surfaces for millions of cycles and long life. Sheet metal is captured with a hook that toggle locks when air actuates the cylinder and remains locked when air is removed. Full Toggling Mechanism Locks when air is off imail: [email protected] www.destaco. 1-888-DESTACO

DE-STA-CO Locating Pin Clamps 82P Series Locating Pin Clamp Ordering Information 0 2 16 3, C8 0 5 NPT 82P30 - 5 ■NPT = 1/8" NPT PORTS ■G =1/8" G PORTS (82P25 is supplied with 1/8" G and NPT Ports) SENSOR OPTIONS SEE PAGE 11 FOR MORE INFORMATION NOMINAL PIN DIAMETER 82 SERIES PIN CLAMP CYLINDER DIAMETER 35MM S = HOOK AWAY FROM SWITCH (SHOWN) R = HOOK TOWARD SWITCH While we make every attempt to insure information given is correct, we reserve the right to amend without notice the spcifications given in this document. 6 Email: [email protected] www.destaco.com 1-888-DESTACO

DE-STA-CO Locating Pin Clamps nji nom) coMPmn 82P Series Locating Pin Clamp Features and Benefits 6 K 9 45 W MODEL NUMBER 25 = 82P25 30 = 82P30 35 = 82P35 SHEET METAL THICKNESS SPECIAL MODEL DESIGNATION BASE HEIGHT 25 = 25MM 50 = 50MM P = PIN H = HOOK B = BASE K = PIN, HOOK, BASE KIT (SHOWN) (SEE ILLUS - I BOX BELOW) S = SPECIAL ■PIN HEIGHT (FOR WELD SLAG RESISTANCE OPTION PIN HEIGHT SHOULD BE 60MM MINIMUM) PIN DIAMETER (MM) (CUSTOM-MADE TO DIAMETER WITHIN RANGE OFFERED BY PIN MODEL) 13.00 - 28.00 (82P25-1) 15.00 - 32.00 (82P30-5) 28.00 - 78.00 (82P35-5) Other diameters available. Contact DE-STA-CO...

DE-STA-CO Locating Pin Clamps 82P Series Pneumatic Locating Pin Clamp 82P25 (25mm Cylinder) - General Dimensions 100.5 o O I 60 O CN k-> CN M6 (3) \|7 10mm o M6 (2) \F 10mm 9 25 - CN 0 6 H7 ~& 10mm I 0 6 H2 (3) \I7 10mm 12 1/8 "NPT" -Shown with world clamp switch 1/8 "G" 40 60 While we make every attempt to insure information given is correct, we reserve the right to amend without notice the spթcifications given in this document. 8 Email: [email protected] www.destaco.com 1-888-DESTACO

DE-STA-CO Locating Pin Clamps nji nom) coMPmn 82P Series Pneumatic Locating Pin Clamp 82P30 (30mm Cylinder) - General Dimensions _ liHtח^fl iחi i ni K ® ® ® ® h 11 1 Ul 1 l_W^ ■ 1FCח■ \ 115 105 CN Shown with weld immune pin 2 4 30 2 3 0 8 H7 (2) Q \|/ 14mm J] jr M8 (4) \]7 14mm 0 8 H7 (2)^ & 14mm m r-ח ©- M8 (4)-\ 14mm NPT OR G Shown with world clamp switch imail: [email protected] www.destaco. 1-888-DESTACO

DE-STA-CO Locating Pin Clamps 82P Series Pneumatic Locating Pin Clamp 82P35 (35mm Cylinder) - General Dimensions 153 o ©S ■ e n~f 115 col 105 Shown with Weld Immune Pin 30 o o- 3 CM 8 H7 (2). ^714mm M8 (4) -^714mm LU CO co CM O Shown with World Clamp sensor NPT or G While we make every attempt to insure information given is correct, we reserve the right to amend without notice the spcifications given in this document. "|0Email: [email protected] www.destaco.com 1-888-DESTACO

DE-STA-CO Locating Pin Clamps nji nom) coMPmn 82P Series Locating Pin Clamp Sensor Information Code C8 Turck 10...30 VDC 150mA 4 Pin, M12, Eurofast E4 Pepperl-Fuchs 10...30 VDC 100mA 4 Pin, M12, Eurofast E6 Baluff 10...30 VDC 100mA 4 Pin, M12, Eurofast + DC Voltage -> S01 Unclamped Load S02 Clamped _Load_ Mounting Information NAAMS Section P-37 Inside Mount Bracket Number Shown with: 82P30 Pneumatic Pin Clamp NM-P30-IS NM-P35-IS Shown with: 82P30 Pneumatic Pin Clamp X Direction Shim Z Direction Shim Shim packs are 5mm Z Direction Shim X Direction Shim Y=Center Shim packs are 5mm Contact DE-STA-CO...

DE-STA-CO Locating Pin Clamps 52F and 52R Series Locating Pin Clamp Features and Benefits Introduction Locating Pin Hardened and ground precision tool steel pin Weld Immune Hook and Pin Design Available Can be closed off when clamped and closed off when unclamped (Only available with certain pin options) 52F SERIES In-Line Manual DE-STA-CO's manual pin clamps are designed for prototype build, short run production, and CMM manual pallet systems. The manual clamp is fully toggling to give precision hold down for geometric fabrication or precision measuring. DE-STA-CO's geometric pins are full 360°...

DE-STA-CO Locating Pin Clamps nji nom) coMPmn 52F and 52R Series Locating Pin Clamp Opration Principe DE-STA-CO's 52F and 52R Locating Pin Clamps are made using a fully enclosed body with hardened steel bushing wear surfaces for millions of cycles and long life. Sheet metal is cap-tured with a hook that toggle locks when handle is manipulated into the closed position and remains in locked position until the handle is released.

DE-STA-CO Locating Pin Clamps 52F and 52R Series Manual Locating Pin Clamp Adjusting the clamping hook DE-STA-CO 52F and 52R Series manual Locating Pin Clamp can be adjusted to accept different sheet metal thicknesses, and has an adjusting range of 0 - 40mm. This is done by adjusting the height of the hook in the clamped position. Please follow the procedure below to adjust the hook. 1) Close handle to bring hook to clamping position 2) Remove the back cover. The cover is located on the bottom of the 52R series and on the side of the 52F series. 3) Loosen the set screw located in the clevis,...

The 52C Sries of the Manual Pin Clamps are cable operated clamps used on fixtures, CMM clamping systems and pallet applications where space or location of the clamp requires remote actuation. The heavy duty stainless steel cables are high-density polyethylene coated for smooth operation. The cable has a minimum bend radius of 6" with standard lenghts of 3, 6, and 10 feet. imail: [email protected] www.destaco. 1-888-DESTACO
