VLT® OneGearDrive StandardTM Feature Benefit • High-efficiency bevel gear drive • High break away torque • High system efficiency incl. frequency converter • Save money and energy – up to 25% power savings compared to conventional systems • Permanent-magnet three-phase synchronous motor • Better than Super Premium Efficiency class IE4 • Motor without cooling fins and fans • Ensure a measurable reduction of airborne germs • 10-pole motor for continuous duty S1 • High torque available • Available hollow shaft diameters: 30, 35 and 40 mm • Flexible adaption to customer standards • Completely smooth enclosure leaves no crevices or dirt traps • Easy to clean • Safe production • Motor and resolver connection with Danfoss CleanConnect® stainless steel circular connector (OGD Hygienic) • Safe connection in wet areas • Fast replacement • High cleanability • Motor, resolver and brake connections via terminal box with CageClamp® technology (OGD Standard) • Fast, reliable connection • Lower installation cost • Aseptic coating (standard for OGD Hygienic, optional for OGD Standard) • Resistant to cleansing agents and disinfectants (pH 2..12) • Optional Antibac® antibacterial coating • Reduced cleaning time and costs • Surface coating and food grade lubricants compliant with FDA and NSF requirements (OGD Hygienic) • Reliable and direct use in product handling areas High degrees of protection: • IP67 and IP69K (OGD Hygienic) • IP65 and IP67 (OGD Standard) • Unrestricted use in wash down areas • High protection in wash down areas In combination with VLT® AutomationDrive FC 302 or VLT® Decentral Drive FCD 302 • System voltage 380 ... 500 V +/-10% • Widely usable • System frequency 50/60 Hz • Available as central and decentral solution • Output frequency 0 – 250 Hz • Wide speed control range • Operation with or without speed feedback (resolver option) • Open loop operation for typical conveyor applications • Resolver option allows closed loop operation and synchronising/positioning applications Product range: • Power rating................................1.5 - 3 kW • Max speed...............3000 RPM @ 250 Hz • Frequency...............................max. 250 Hz • Current.........................................max. 7.2 A Constants: • Torque...................................kt 1,7 Nm/A • Voltage....................kc = 120 V/1000 rpm VLT® OneGearDrive The compact design of the VLT® OneGearDrive makes it predestined for use in transport and conveying systems as well as machines and equipment. The drive has been designed especially for use in the food and beverage industry allthough this new generation of transmission product offers significant benefits in all conveyor drive applications. Compared to traditional systems the VLT® OneGearDrive covers all applications with one drive size and only a low number of variants, reducing spare part inventory and easing engineering thanks to uniform mechanical dimensions. The high-efficiency bevel gearing with permanent-magnet three-phase synchronous motor offers high energy efficiency – up to 25% power savings compared to conventional systems. The VLT® OneGearDrive comes in two versions, the OneGearDrive StandardTM for use in dry and wet production areas and the OneGearDrive HygienicTM for use in wet areas, areas with high cleaning intensity and aseptic and clean room production areas. In both versions the complete smooth, easy to clean surface without cooling fins prevents pockets of dirt from forming and allows cleansing agents to drain off freely. The fanless motor avoids the risk of air-borne germs and dirt particles being drawn in and then expelled back into the surrounding air. Facts about our products VLT® OneGearDrive HygienicTM MAKING MODERN LIVING POSSIBLE
