LAMPOPTIONS OPTIONS •2 x 1W high intensity white LED •Maintained, 3 hour duration•Can be set to operate as non-maintained luminaire•Choice of legend pictograms and trim colour finish combinations•Intellem self test. Technology detailed on page 202•EasiCheck™ addressable testing. System detailed on page 195•Central static industrial inverter system versions•Note - BSI Kitemark pending MATERIALS •Body - steel, powder coated in Permawhite finish•Trim/legend assembly - steel, powder coated in Permawhite or textured dark grey finish, or electro-plated in satin chrome finish•Legend panel (pre-fitted to trim) - clear acrylic withvariable pitch dot, screen print•Industrial batteries (self-contained versions) - sealed nickel cadmium SPECIFICATION Self contained - To specify state: Robust, shallow profile selfcontained emergency exit sign luminaire, fully compliant with EN1838, first fix base incorporating BESA and conduit entries.Trim/legend assembly, fitted with variable dot pitch pictogram,edge lit by ultra long life LED industrial light source, with white/textureddark grey/satin chrome trim finish, as Menvier Britesign range,part no. ________Self-test/Static inverter slave - To specify state: Intelligentself-testing/Static inverter system compatible slave, robust, shallow profile emergency exit sign luminaire, fully compliant withEN1838, first fix base incorporating BESA and conduit entries.Trim/legend assembly, fitted with variable dot pitch pictogram,edge lit by ultra long life LED light source, with white/textureddark grey/satin chrome trim finish, as Menvier Britesign range, part no. ________ INSTALLATIONNOTES •Suitable for wall mounting•First fix body with 3 x 20mm conduit entries•BESA entry on rear, or direct screw fix via keyhole slots•Can be set to operate as maintained or non-maintained•Maintained requires addition of a switched live supply•Trim/legend assembly (order separately) screw fixed to base •Trim/legend assembly supplied with pre-mounted LED light source and chosen legend pictogram fitted

260

DIMENSIONS MAXIMUM VIEWINGDISTANCE
WD H

30 metres

W (mm)H (mm)D (mm) 38027550 CATALOGUENUMBERSSystem ModeCat. No.Weight (kg)
Britesign luminaire body - order trim/legend assembly separately MaintainedBSM1.8 Intellem Infra-Red - MaintainedBSM/IR1.8 Intellem Self-Check - MaintainedBSM/IS1.8 230V AC Static inverter system slaveBS2301.3 DescriptionPictogramTrim colour finish WhiteDark GreySatin ChromeWeight (kg)
Trim/Legend assembly - order luminaire body separately Down arrowBS/W/ADBS/G/ADBS/C/AD1.75 Left arrow BS/W/ALBS/G/ALBS/C/AL1.75Right arrowBS/W/ARBS/G/ARBS/C/AR1.75 Also available with EasiCheck™ automatic testing functionality - see page 195 for system featuresContact our Technical Support and Application department for further details - 01302 303350 Emergency Luminaires - Exit Signs

BRITESIGN
