SAFETY AND RELIEF VALVES MADE IN THE USA Pressure relief valves and accessories for a wide range of commercial, industrial, and OEM applications.

2 Customer Service 1-704-841-6000 Table of Contents PRODUCTS Valve Selection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 10 Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6 10-322 / 10-512 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8 10-600 Series . ....

About Conbraco www.apollovalves.com 3 American-made, over 80 years strong American Lubricator and Brass Co. and Sterling & Skinner Manufacturing Co., two established Detroit-based manufacturers of brass valves and fittings, merged in 1928. They adopted a new name, Consolidated Brass Company, and Conbraco Industries was born. Now 80 years later, from its headquarters near Charlotte, N.C., Conbraco operates more than one million square feet of ISO 9001:2000 certified manufacturing and warehousing space at four Carolinas facilities. Reflecting its commitment to vertically integrated manufacturing,...

www.apollovalves.com 5 10-408 10-418 10 Series Brass/bronze safety relief valves protect ASME Section IV hot water heating boilers and hydronic heating systems. High capacity design features corrosion resistant construction. Brass, satin or polished chrome finishes available. ASME Section IV Inlet Size 3/4" - Outlet - 3/4” & 1" Set Pressure 20-150 psi Maximum temperature service: 250°F Applications: Ideal for use with hot water boilers and hydronic heating systems. Features • Pressures from 20 to 150 psig • Registered in all Canadian provinces and territories, CRN #0G8547.5C • Stainless steel...

www.apollovalves.com 7 Section VIII Pressure Vessels National Board capacity-certified safety valves; brass body with optional satin or polished chrome finish. Protects against excess pressure from thermal expansion and steam caused by failure of Btu input controls. ASME Section VIII Sizes 1/2" and 3/4" Set pressures 15 to 60 psig@312°F max National Board Certified Capacity Applications: Ideally suited for OEM applications such as steam carpet and jewelry cleaners, autoclaves, sterilizers, commercial pressure cookers, steam jacketed kettles, dental equipment, coffee makers and similar equipment....

8 Customer Service 1-704-841-6000 Item Component Material 1 NOZZLE BRASS ASTM B-16 2 BODY BRASS ASTM B-16 3 NAMEPLATE ALUMINUM 4 DRIVE SCREW STEEL, ZINC PLATED 5 HANDLE STEEL, ZINC PLATED 6 COTTER PIN STEEL, ZINC PLATED 7 STEM BRASS ASTM B-16 8 SPRING STAINLESS STEEL 9 SPR. WASHER BRASS ASTM B-16 10 DISC BRASS ASTM B-16 11 SEAT TEFLON FACED EPDM 12 WASHER BRASS ASTM B-16 10-322 Materials Item Component Material 1 NOZZLE BRASS ASTM B-16 2 BODY BRASS ASTM B-16 3 NAMEPLATE ALUMINUM 4 DRIVE SCREW STEEL, ZINC PLATED 5 PULL RING STEEL, ZINC PLATED 6 CAP BRASS ASTM B-16 7 DISC ASSEMBLY BRASS, SILICONE...

12 Customer Service 1-704-841-6000 12-200 Series Low Pressure Steam Heating Boiler Safety Valves Medium capacity safety valves protect ASME Section IV low pressure steam heating boilers. Cast bronze, full nozzle design features PTFE faced elastomer soft seating for dependable operation. ASME Section IV Sizes 2, 2-1/2" and 3" Set pressures 5-15 psi Applications: Medium and large commercial and industrial steam heating and processing boilers. Features • All bronze construction • PTFE-coated O-ring seat seal • 3/8" NPT side tapping for drain • Rust-proofed steel spring • Top guided, high capacity...

www.apollovalves.com 13 ASME Section IV bronze safety valves protect small to medium low pressure steam heating boilers. Three design configurations feature top guiding and raised seating area for extended service life. Available top and side discharge models. ASME Section IV Sizes 3/4"-1-1/2" Set pressure 5 to 15 psi Applications: Low pressure steam heating and supply boilers. Features • Flat seat, PTFE faced disc for positive seal • Standard set pressure of 15 psig • Positive drainage of condensate from seat area • No. 13-101 is top outlet discharge • Registered in all Canadian provinces and...

Set Pressure psig Suffix 5 -03 6 -04 8 -05 10 -06 12 -07 15 -08 14 Customer Service 1-704-841-6000 ASME Section IV Set pressures from 5 to 15 psig. Sizes 2", 2-1/2" and 3". Applications: The 14 Series is an ASME Section IV high capacity steam safety valve for use with medium and large size commercial and industrial heating boilers. Features • One piece body, all bronze construction • Rust proofed steel spring • Chrome plated seat, PTFE coated disc • PTFE coated EPDM O-ring for positive seal • 3/8" NPT side tapping for drain connection • Valves are capacity certified by the National Board at 15...

16 Customer Service 1-704-841-6000 Model Size Dimensions(in./mm.) Wt./Ea Number (in./mm.) A B C (lbs./kg.) 14-X05 2 x 2 3 6-1/2 3-1/8 8.4 50M x 50F 76 165 79 3.81 14-X06 2-1/2 x 2-1/2 3-1/2 7-5/8 3-1/2 12.5 65M x 65F 89 194 89 5.7 14-X07 3 x 3 4-1/8 8-3/4 3-7/8 17.0 80M x 80F 105 222 98 7.7 Dimensions and Weights High volume air relief valves designed for low pressure air and gas service. Rugged bronze construction features elastomer soft seating and TFE coated discs for dependable operation. Non-ASME code air and gas service Inlet sizes 2”, 2 1/2” and 3” Set pressures 4 to 22 psig @ 400°F max....

www.apollovalves.com 17 Model Size Dimensions(in./mm.) Wt./Ea Number (in./mm.) A B C (lbs./kg.) 14-605 2 x 2 3 6-1/2 3-1/8 8.4 50M x 50F 76 165 79 3.81 14-606 2-1/2 x 2-1/2 3-1/2 7-5/8 3-1/2 11.8 65M x 65F 89 194 89 5.4 14-607 3 x 3 4-1/8 8-3/4 3-7/8 16.3 80M x 80F 105 222 98 7.4 Dimensions and Weights 14-600 14-600 Series Vacuum Relief Valves Model Numbering System 14-600 Series Vacuum Relief Valves EXAMPLES: 14-607-V14 3" Vacuum relief valve set at 14 Hg" Connect vacuum source here B A C 14 6 05 V12 Series Body / Cap Style Inlet Number and Service Connection Relief Pressure 14 6 = Vacuum Relief...
