Pipeline Strainers @
Strainer Screen Data
MAGNETIC INSERTS
Magnetic inserts may be furnished, which when placed inside the strainer screen or basket, will collect very fine ferrous metal particles entrained in the liquid thus protecting equipment against abrasive damage.
Common Perforations And Mesh Open Areas
Our strainer screens are made in a variety of perforations and mesh openings to best suit the application. Standard material is 304 stainless steel. Other screen materials are available on special request. When screens are constructed of very fine mesh wire cloth, they are reinforced with a rigid outer shell of perforated sheet. Perforated screens are made of sheet stainless steel, the thickness of which is not greater than half the size of the perforations.
OPENING RATIOS
The following steps should be taken to determine the ratio of openings through strainer screens to the area of inlet pipe size.
1. Determine the size mesh or perforation required to give the desired particle retention.
2. Multiply the total area of the screen by the percent of open area of the perforation or mesh material. The result is the open area of the screen. (Total area of the screen is given in the dimensional charts).
3. The open area of the screen divided by the area of the pipe will give the ratio of open area of the screen to the area of the pipe.
4. To determine the ratio of open area to the pipe on mesh lined reinforced screens, complete step two (2) to find the open area of the mesh. Multiply the open area of the mesh by the percent of open area of the reinforcing material. The result divided by the area of the pipe will be the ratio of open area of the screen to the area of the pipe.
Mesh I squarr^^
% Open Area
^^H
Actual % Open Opening Area
pening
20 40 60 80 100
0.034 0.015 0.010 0.007 0.006
46.2 36.0 30.5 31.4 30.3
0.027
1/32 3/64 1/16 1/8 1/4
0.027 0.033 0.045 0.062 0.125 0.250
23
29
37 30 40 48
Area of Schedule #40 Pipe (IN2)
Pipe Size
Pipe Size
Pipe Size
Pipe Size
Pipe Size
Pipe Size
Inches
Area
Inches
Area
Inches
Area
1/2
0.304
3
7.393
10
78.860
3/4
0.533
3-1/2
9.886
12
111.930
1
0.864
4
12.730
14
135.280
1-1/4
1.495
5
20.010
16
176.720
1-1/2
2.036
6
28.890
18
223.680
2
3.355
8
50.030
2-1/2
4.788
Carbon Steel: ASTM A216 Grade WCB Stainless Steel: ASTM A351 Grade CF8M (316)
Pressure - Temperature Ratings
For Steel and Alloy Strainers. Pressure temperature ratings shown are for non-shock conditions.
Class 150 1
Class 300 I
Degrees F.
Carbon Steel
Stainless
Steel
Carbon
Steel
Stainless
Steel
Carbon
Steel
Stainless
Steel
-20 to 100 200
285 260
275 235
740 675
720 620
1480 1350
1440 1240
300
230
215
655
560
1315
1120
400
200
195
635
515
1270
1025
500
170
170
600
480
1200
955
600
140
140
550
450
1095
900
650
125
125
535
445
1075
890
700
110
110
535
430
1065
870
750
95
95
505
425
1010
855
800
80
80
410
420
825
845
850
65
65
270
420
535
835
900 950
50 35
50 35
170 105
415 385
345 205
830 775
1000 1050
20
20
50
350 345
105
700 685
1100
305
610
1150
1200
235 185
475 370
1250
1300 1350
145 115 95
295 235 190
1400 1450
75 60
150 115
1500
40
85
Skilled specialists in our engineering department are available to provide customer assistance on special straining applications.
