Colombo Filippetti - Oscillating Drives - CF3 Medium Series - COLOMBO FILIPPETTI - #1

PARALLEL OSCILLATING DRIVES

•bofh1 d5p*13qp

ir

Prism- shaped sealed cast iron housing

Outer surfaces machined, with support on 6 sides

Possibility of mounting housing In all positions

Parallel shafts in Input and output

Roller bearings on opposite taper roller shafts

Oil-bath lubrication

Worm gear reducer directly splined to housing Precise repeatable index motion Self locking In dwell and zero backlash Smooth and shock-free movement Bi-directional sense of motion

CF1121 09-06

Via Rossini, 26 I-24040 CAS I RAT E D'ADDA -BG -Tel 0363-3251 Fax 0363-325252

http://www.cofil.it - E-mail cofil@cofil.it
