USA: +1 800.337.9423 +1 513.831.3211 • Belgium: +32 (0)13 53 95 47 • Germany: +49 (0)6551 9606.0 Asia-Pacific: +1 513.831.3211 X709 • Canada: +1 800.337.9423 X501 • Latin America: +52 (81)10 97 0445 R1500 Reformer: Dry Ice Pellet-to-Slice Superior slice production in a minimal footprint Reforming pellets into slices reduces dry ice consumable cost and is safer for the operator compared to traditional block cutting processes. The pellet-to-slice reforming process eliminates hazards from cutting block and reduces CO2 sublimation loss by ~80% – producing less CO2 “smoke.” Cold Jet’s R1500 Pellet-to-Slice Reformer is fully automated, with flexibility to reform 0.12” to 0.6” (3 mm to 16 mm ) dry ice pellets or nuggets into 5” x 8” x 3/4” (125 x 210 x 25 mm) slices. Combine with the P1500 Pelletizer to produce and reform on demand up to 475 slices an hour of high density pellets or nuggets into slices. Hydraulic Power System       Power & Control Enclosure Attached    Human Machine Interface (HMI)       Quick Change Press Heads         DIMENSIONS WEIGHT POWER HYDRAULICS NOISE 48” x 93” x 76” (122 x 236 x 193 cm) 4,000 lbs (1,800 kg) 380/415 or 460/480 VAC 3-phase 50/60Hz 15 kW motor pump 26 gallons/min (100 L / min) Under 80 dBA (at 6.5 feet / 2 meters) Minimal Footprint  ! " !#$ ! Conveyor Slice Exit          %   &' () " $!  * SureFlow Dosing System +     Operational & Maintenance • Best output to footprint ratio • 24/7 production capable • Easily integrated with a pelletizer • Minimal energy consumption SureFlow System • Uses pellets or nuggets • Superior slice quality with <2% breakage • Weighing within +/- 50g of specification Quick Change Press Heads • Change dimension of press in <10 minutes • Vary slice weights at the touch of a button HMI Touch Screen • Full diagnostic capability • Vary slice thickness (¾” up to 2” or 18 up to 50 mm) • Tune critical parameters (i.e. pressure & cycle time) • Remote diagnostics ready (i.e. Siemens S7 PLC with PROFIBUS communication) KEY BENEFITS www.coldjet.com
