Group: CLARK Material Handling
Catalog excerpts
• Two foot steps with traction plates quickly and safely make entry/exit easy... from either side. • The spacious operator compartment includes an easy to read color display. Real time information including error codes for the transmission and engine are shown in the LCD display. With the combination of a 67 kw engine, fully automatic 3-speed transmission, wet disc brakes and rugged chassis design, the GEN2 C60-80 provides the exceptional performance, maneuverability and durability in its class that you’ve come to expect from CLARK. Highly Maneuverable, Easily Serviceable, Broadly Flexible,...
Open the catalog to page 2Maximum Visibility + Minimum Fatigue = Ultimate Safety & Maximum Productivity 8 metric tons With a capacity of up to 8,000 kg. the CLARK C60/70/75/80 is all the truck you will ever need. • Nested Upright Rails, Overhead Guard Safety Bars (running parallel to operator’s line of sight) and dual primary cylinders with no center cylinder expand the vision window and reduce product damage.
Open the catalog to page 3Optional Equipment • Wide range of upright options • Double auxiliary valve • Double hose adaptation • Integral sideshifters • Integral fork positioners • Fork options • Strobe lights C60-80 STANDARD FEATURES & BENEFITS PARKING BRAKE Simple & Error Proof • Hand operated parking brake activates brakes • Transmission disengages when parking brake is set preventing driving against park brake. "BUILT TO LAST®" CHASSIS • Heavy duty, welded, integral box frame assembly. • Integral hydraulic & fuel tanks. • Wrap-around side frame members for rigidity. • Integral battery & tool box compartments....
Open the catalog to page 4"SMART SHIFT" TRANSMISSION Fully Automatic • 3-Speed Powershift Transmission is standard on LPG & Diesel models. • Operator friendly, automatic upshifting and downshifting. Modulated Shift Protection • Smooth engagement, cushioned shifting. Electrically Controlled • No adjustments required. Heavy Duty • Robust components for longer life. Inching Valve • with Left Brake Pedal operation allows for precisely controlled travel speeds during high speed lifting. OPTIONAL OPERATOR CAB Maximum Visibility • Unique overhead guard design minimizes vision obstruction of door pillars. 180° Fold & Lock...
Open the catalog to page 5Over 102 countries. Represented by 350 dealers. At over 500 Locations The best choice for: • Total cost of ownership • Maintenance costs • Value for money • value retention • Purchase price And don´t Forget ... You brought the original ... Keep it that way ... We are focusing on providing excellent off-the-shelf availability of genuine Clark, quality parts, quick response time and competitive pricing.
Open the catalog to page 6Dependable Parts = Dependable Trucks • We don´t just build forklifts. As a company, we are also focused on providing our customers with the best possible technical service support and aftermarket parts available. • The CLARK PartsPRO® System is our industry-leading electronic parts and service documentation tool that provides dealers with a quick and accurate method of identifying parts for every CLARK forklift build since 1961. Parts Pro® ensures the availability of the most current technical information and has the unique capability to create parts manuals specific to your mixed CLARK...
Open the catalog to page 7® Clark europe GmbH Neckarstraße 37 · D-45478 Mülheim an der Ruhr Tel: +49 (0)208-37 73 36-0 · Fax: +49 (0)208-37 73 36-36 Info-europe@clarkmheu.com · www.clarkmheu.com Dealer © 2010 CLARK Material Handling Company Printed in Germany GEN2 C60/70/75/80
