| TP-L0260EN Thermal Imaging Sensor | |||||||||||||||
| CHI | |||||||||||||||
| TP-L series is a compact infrared thermal imaging sensor utilizing a thermopile array detector. This CHINO developed detector allows the sensor to measure real time temperature. Ethernet connectivity allows the sensor to communicate with PC running CHINO Imaging Software or customer's LAN. ■ FEATURES •Easy to Use and Implement •2000 pixel Resolution •Built-In Alarms •IP65 / NEMA4 ■ MODEL TP-L0260EN | |||||||||||||||
| ■ SPECIFICATIONS Temp Range: -20 to 300°C Resolution: 0.5C (At black body temperature of 100C) Accuracy: ±2% of reading or ±3C whichever lager (At Ambient temp of 25C ±2C) | |||||||||||||||
| Detector: Wavelength: Viewable Angle: 60"X60" Radius Resolution: 21.8mrad Frame Speed: 3fps (1fps for alarm output) Focus: Fixed focus Emissivity: 0.10 to 1.00 Ethernet: 10BASE-T/100BASE-TX Alarm: 2 points(Non voltage contact output) Power Supply: 12 to 24V DC Power Consumption: Max 2VA (At 12V DC) Inrush Current*1: Max 1.3A (At 12V DC) Working Temp: -10 to 50C Working RH: 10 to 80%RH (No dew condensation) Casing: Polycarbonate (Color: Black) Weight: Approx. 150g (sensor only) Protection: IP65 (w/ provided exclusive cable and tripod screw) Standards: CE (EN61326 Annex A) | |||||||||||||||
| *1 The inrush current should be considered for the selection of power | |||||||||||||||
| PSE-702 | |||||||||||||||
