| PERFORMANCE SPECIFICATION | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■ APPLICATION SOFTWARE •Requirements OS : Windows 2000 (SP4 or later)/XP/Vista (Windows XP or later recommended) * NET Framework 2.0 or later (required) Memory : Windows 2000/XP.....1GB recommended (512MB or more) : Windows Vista.....2GB or more recommended CPU : Windows 2000/XP.....1.5GHz or faster recommended : Windows Vista.....2GHz or faster recommended * "Microsoft" and "Windows" are either trademarks or registered trademarks of Microsoft Corporation, USA. * "Intel" and "Pentium" are either trademarks or registered trademarks of Intel Corporation, USA. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| •Basic function When the LAN settings are completed correctly between a PC and the thermal image sensor and the LAN communication is established, thermal image screen will appear. The thermal images up to 4 sensors can be displayed with this application software, and the simultaneous display for 4 images and the individual display for each sensor can be switched. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| •Various settings of sensor LAN settings / Alarm settings of the sensors / Emissivity setting •Data storage Image temperature data storage (temperature data/csv for 2000 pixels) / Thermal image screen storage (JPEG) •Image processing Screen averaging / Spatial smoothing / Median filter / Rotation / Maximum & Minimum values indications | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| •Trend graph | Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| By specifying a graph area, data can be displayed by the trend graph and the graph data can be stored by setting. (Max. 8 areas) •Alarm settings by the application software By specifying a graph area, alarms can be set. (Max. 8 areas) Separately from the alarm settings of the sensor, the alarm screening by the application software can be performed. (Max. 8 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Trend graph | Alarm screening | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| /\ The alarm of the sensor is interlocked with the contact output, but the contact output cannot be activated with the alarm by the / I \ application software. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■ PRECAUTIONS •This product contains an item under export control. Therefore, delivery is subject to necessary export licenses by the Ministry of Economy, Trade and Industry (METI) in Japan. It is strictly regulated to export the product to certain area. In case of retransfer, resale and/ or reexport of the product, prior authorization by the METI is required. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Specifications subject to change without notice. Printed in Japan (I) 2009. 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
