The most frequently fitted protection instruments may be divided into seven groups:
1. Temperature monitoring
1.1. Monitoring the temperature of the cooling liquid
• Indicator thermometer with maximum pointer without electrical contacts (PK 3549)
• Indicator thermometer with maximum pointer and two electrical contacts (PK 3544)
• Remote thermometer with maximum pointer and two electrical contacts (PK 3546)
• Thermostat with one or two electrical contacts (PK 3611 and PK 3612)
• PT 100 resistance-type thermometer (PK 3543)
1.2. Monitoring the temperature of the windings
• Winding temperature indicator with maximum pointer and two electrical contacts (PK 3536)
2. Liquid level monitoring
2.1. Liquid level monitoring in integrally filled and hermetically sealed transformers
• Vertical magnetic oil level gauge (PK 3519)
2.2. Monitoring the liquid level in hermetically sealed transformers with gas cushion
• Float oil level indicator (PK 3527)
2.3. Monitoring the liquid level in transformers fitted with a conservator
• Gauge glass (PK 3511)
• Prismatic oil level gauge (PK 3516)
• Horizontal magnetic oil level indicator without or with contacts (PK 3523)
3. Internal overpressure protection
• Pressure relief device without indicator (PK 3735)
• Pressure relief device with indicator flag (PK 3730)
• Overpressure relay with two electrical contacts (PK 3733)
4. Protection of the liquid against moisture ingress
• Silica gel air dryer (PK 3750)
5. Multi-purpose protection
• Buchholz relay with two normal (NO) contacts (PK 3710)
• DGPT2 relay with four electrical contacts (PK 3760)
• Hermetic protector with gas sample valve and one electrical contact (PK 3520)
6. Protection against physical contact
• Plug-in bushings and connectors (inside cone model and outside cone model)
• Standard and special cable boxes
7. Overvoltage protection
• Arcing horns (see also photo 3)
• Surge arresters
For a more detailed description, ask our marketing communication department to send you the
separate brochure on protection equipment. Technical sheets of each individual instrument are
also available on request (PK reference number required).
