SINGLEPHASE

Solid state relays

Innovation, Performance & Design !

Innovations : Performance :

Screw connection up to 50mm

2

Designed for all types of loadsRemovable control terminalsCurrent from 12 to 125A Removable IP20TMS

2

technology 4

th

generation with very long life time expectancyVersatile, easy and quick connectionsOutput voltage from 24 to 690 VAC (600V-1200V-1600V peak) Same screwdriver for outputs and inputsVery low zero-cross level Tightening on metal baseplate not on plasticLarge and regulated AC and DC input voltage SSR, mains and load statusControl status LED Less potting resin : environmentally friendlyVery high immunity according IEC/EN61000-4-4 (bursts) and IEC/EN61000-4-5 25 to 30% lighter than the SC range(spikes) : 4KV with no change of stateEMCcompatible for industrial environment UL/cUL, VDE (EN60950), IEC/EN60947-4-3, CE marking Itsm up to 2000A and I

2

t up to 24000A

2

S allowing loads with high inrush currentProtection against industrial circuit breaker

SO7 Range

Typical applications : Motors (AC-53), inductive loads and phase angle control applications.Voltage protection on input (transil) and output (RC and VDR)

PRODUCTREFERENCE Switchingcurrent Switchingvoltage PeakvoltageControlvoltageControlcurrentI

2

tDimensionsmm

SO745090

50A12-275VAC600V3-32VDC Ic <13mA2500A
2 s

SO747090

75A12-275VAC600V3-32VDC Ic <13mA7200A
2 s

SO763090

35A24-510VAC1200V3,5-32VDC Ic <13mA1250A
2 s

SO765090

50A24-510VAC1200V3,5-32VDC Ic <13mA2500A
2 s 45 x 58,5 x 30

SO767090

75A24-510VAC1200V3,5-32VDC Ic <13mA7200A
2 s

SO768090

95A24-510VAC1200V3,5-32VDC Ic <13mA14400A
2 s

SO769090

125A24-510VAC1200V3,5-32VDC Ic <13mA24000A
2 s

These products should be mounted on heatsinks in order to reach nominal current. Thes products should be mounted on heatsinks in order to reach nominal current.

SO8 Range

Designed for most types of loadsZero cross with low zero-cross level (<12) Voltage protection on input (transil) with very high immunity according to IEC/EN61000-4-4IP20 protection Control current < 13mA for all the voltage range at any operating temperature control status LED

PRODUCTREFERENCE Switchingcurrent Switchingvoltage PeakvoltageControlvoltageControlcurrentI

2

t Dimensionsmm

SO842074

25A12-275VAC600V3-32VDC Ic <13mA600A
2 s

SO842974

25A12-275VAC600V20-265VAC/DC Ic <10mA600A
2 s

SO843070

35A12-275VAC600V3-32VDC Ic <13mA1250A
2 s

SO843970

35A12-275VAC600V20-265VAC/DC Ic <10mA1250A
2 s

SO845070

50A12-275VAC600V3-32VDC Ic <13mA2500A
2 s

SO847070

75A12-275VAC600V3-32VDC Ic <13mA7200A
2 s

SO848070

95A12-275VAC600V3-32VDC Ic <13mA14400A
2 s

SO849070

125A12-275VAC600V3-32VDC Ic <13mA24000A
2 s

SO863070

35A24-510VAC1200V3,5-32VDC Ic <13mA1250A
2 s

SO863970

35A24-510VAC1200V20-265VAC/DC Ic <10mA1250A
2 s 45 x 58,5 x 30

SO865070

50A24-510VAC1200V3,5-32VDC Ic <13mA2500A
2 s

SO865970

50A24-510VAC1200V20-265VAC/DC Ic <10mA2500A
2 s

SO867070

75A24-510VAC1200V3,5-32VDC Ic <13mA7200A
2 s

SO867970

75A24-510VAC1200V20-265VAC/DC Ic <10mA7200A
2 s

SO868070

95A24-510VAC1200V3,5-32VDC Ic <13mA14400A
2 s

SO868970

95A24-510VAC1200V20-265VAC/DC Ic <10mA14400A
2 s

SO869070

125A24-510VAC1200V3,5-32VDC Ic <13mA24000A
2 s

SO869970

125A24-510VAC1200V20-265VAC/DC Ic <10mA24000A
2 s
2

6

SO885060

50A24-690VAC1600V3,5-32VDC Ic <12mA2500A s

SO887060

75A24-690VAC1600V3,5-32VDC Ic <12mA7200A
2 s

SO888060

95A24-690VAC1600V3,5-32VDC Ic <12mA14400A
2 s
HIGH VOLTAGERELAY

SO889060

125A24-690VAC1600V3,5-32VDC Ic <12mA24000A
2 s
