| | | SINGLE PHASE | | |
| | | |
| | | |
| | | POWER SSRs with diagnostics | | |
| | | |
| | | Status of the SSR and the load without external power supply. This range is patented. Status output can be chained. Fault condition alarms • Line or load open • Short circuit output Diagnostic description : | | |
| | | |
| | | | | | | | | | | | | | | Control | Control LED | Mains | Load | SSR | Status LED | Output status | | | | 0 | O | Yes | OK | OK | O | closed | | | | 1 | o | Yes | OK | OK | o | closed | | | | 0 | o | No | OK | OK | o | open | | | | 1 | o | No | OK | OK | o | open | | | | 0 | o | Yes | | OK | o | open | | | | 0 | o | Yes | OK | short-circuit | o | open | | | | 1 | o | Yes | — | OK | o | open | | | | 1 | o | Yes | Ok | short-circuit | o | open | | | | | | | | | | | | | | |
| | | |
| | | | | | | | | | | | | | | | PRODUCT REFERENCE | Switching Current | Switching Voltage | Peak Voltage | Control Voltage | Current Control | I2t | Dimensions mm | | | | SILD845160 | 32A | 70-280VAC | 600V | 3-32VDC | Ic<10mA | 1500A2s | 22,5 x 80 x 116 | | | | SILD865170 | 32A | 150-510VAC | 1200V | 3,5-32VDC | Ic<10mA | 1500A2s | | | | SILD867170 | 35A | 150-510VAC | 1200V | 3,5-32VDC | Ic<10mA | 5000A2s | | | | | | | | | | | | | | | |
| | | |
| | | | | | | | | | | | | PRODUCT REFERENCE | Switching Current | Switching Voltage | Peak Voltage | Control Voltage | | | | SOD843180 | 35A | 70-275VAC | 600V | 4-30VDC | | | | SOD845180 | 50A | 70-275VAC | 600V | 4-30VDC | | | | SOD865180 | 50A | 150-510VAC | 1200V | 5-30VDC | | | | SOD867180 | 75A | 150-510VAC | 1200V | 5-30VDC | | | | | | | | | | | | | | | | | | | Input R | I2t | Dimensions mm | | | | 1 kQ | 1250A2s | 45 x58,5 x 33,6 | | | | 1 kQ | 2500A2s | | | | 1 kQ | 2500A2s | | | | 1 kQ | 7200A2s | | | | | | | | | | |
| | | ^NEW | | |
| | | |
| | | |
| | | |
| | | The SOD products should be mounted on heatsinks in order to reach nominal current. | | |
| | | |
| | | SOD | | |
| | | |
| | | | | |
| | | |
| | | The SCP industrial relays are designed for the start-up of transformer primary circuits and all satured inductance coil loads preventing magnetising current peaks (application note on request) | | |
| | | |
| | | | | | | | | | | | | | | PRODUCT REFERENCE | Switching Current | Switching Voltage | Peak Voltage | Control Voltage | Input R | I2t | | | | SCP49110 | 40A* | 180-280VAC | 600V | 4-30VDC | 1 kQ | 610A2s | | | | SCP69110 | 40A* | 300-480VAC | 1200V | 4-30VDC | 1 kQ | 610A2s | | | | | | | | | | | | | | |
| | | Dimensions mm | | |
| | | |
| | | Reak starting | | 44,5x58,2x27 | | |
| | | |
| | | |
| | | |
| | | "See application note on the data sheet. These products can be procured with high rating current on request. For the start-up of three phase transformers use our new range of SOFTSTARTERS SMCW : (see page 13) or our SVTA / SWTA range (see page 17). These products should be mounted on heatsnk in order to reach nominal current. | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
