SINGLEPHASE SO9 Range with regulated input

Typical applications : Resistive loads (AC-51)Zero cross Control status LED IP20 protection flaps only on request PRODUCTREFERENCE Switchingcurrent

Switchingvoltage

PeakvoltageControlvoltageControl currentI

2

t Dimensionsmm SO9 range with regulated control current. SO9 range with simplified input.

SO941460

12A12-280VAC600V3-32VDCIc<13mA128A
2 s

SO942460

25A12-280VAC600V3-32VDCIc<13mA600A
2 s

SO943460

35A12-280VAC600V3-32VDCIc<13mA1250A
2 s

SO945460

50A12-280VAC600V3-32VDCIc<13mA2500A
2 s 45 x 58,5 x 30

SO963460

35A24-600VAC1200V3,5-32VDCIc<13mA1250A
2 s

SO965460

50A24-600VAC1200V3,5-32VDCIc<13mA2500A
2 s

SO967460

75A24-600VAC1200V3,5-32VDCIc<13mA7200A
2 s

PRODUCTREFERENCE Switchingcurrent

Switchingvoltage

PeakvoltageControlvoltageControl currentI

2

tDimensionsmm

SO942560

25A12-280VAC600V7-30VDCIc<30mA600A
2 s

SO963560

35A24-600VAC1200V8-30VDCIc<30mA1250A
2 s 45 x 58,5 x 30 45 x 58,5 x 30

SO965560

50A24-600VAC1200V8-30VDCIc<30mA2500A
2 s

SO967560

75A24-600VAC1200V8-30VDCIc<30mA7200A
2 s

These products should be mounted on heatsinks in order to reach nominal current. These products should be mounted on heatsinks in order to reach nominal current.

SOR Range

With removable input connector - Spring terminals :Designed for most types of loads.Zero cross with low zero-cross level (<12V)Voltage protection on input (transil) and output (VDR) with very high immunity according to IEC/EN61000-4-4 and IEC/EN61000-4-5 IP20 protection Control current <13mA for all the voltage range at any operating temperature Control status LED Double inputs PRODUCTREFERENCE

Switchingcurrent

SwitchingvoltagePeakvoltageControlvoltageControl currentI

2

t Dimensions mm

SOR842074

25A12-275VAC600V3-32VDCIc<13mA600A
2 s

SOR863070

35A24-510VAC1200V3,5-32VDCIc<13mA1250A
2 s

SOR865070

50A24-510VAC1200V3,5-32VDCIc<13mA2500A
2 s

SOR867070

75A24-510VAC1200V3,5-32VDCIc<13mA7200A
2 s

... we also have a celpac

®

rangewith system diagnostics (see page 11)

7
