INTERFACE

Selection Guide - 12114 Modules

PCB or socket mountPin to pin compatible with electromechanical relays No maintenance AC and DC output Withstand high inrush current Integrated VDR Can drive all type of loads High insulation between input to output Low input current Low leakage current

SLIM Range (miniature)

PRODUCTREFERENCE PRODUCTREFERENCE SwitchingCurrent SwitchingVoltageControlVoltageInput RProtec.Specifications Specifications Dimensions mm

SLA01220

2A12-280VAC3-10VDC320 Ω RCAC output28x5x15
AC

SLA02220

2A12-280VAC7-20VDC1100 Ω RCAC output28x5x15

SLA03220

2A12-280VAC18-32VDC3 k Ω RCAC output28x5x15

SLIM5mm

SLD01205

4A0-32VDC3-10VDC320 Ω TransilDC output28x5x15

SLD01210

2,5A0-60VDC3-10VDC320 Ω TransilDC output28x5x15
DC

SLD02205

4A0-32VDC7-20VDC1070 Ω TransilDC output28x5x15

SLD03205

4A0-32VDC18-32VDC3 k Ω TransilDC output28x5x15

SLD03210

2,5A0-60VDC18-32VDC3 k Ω TransilDC output28x5x15

Other miniature solid state relays can be procured (SKM, SKN) : please contact us

1

Fig n°

ESD01000

SP/ST base for PCB for one relay1

2

ESD08100

8 SLIM module base2

SP-ST Range (standard)

AC and DC from 1 to 5A, protection by VDR or built-in transil, come in 15,7 mm (ST Series) and 25,4 mm (SP Series).

1

PRODUCTREFERENCE SwitchingCurrent SwitchingVoltageControlVoltageInput RProtec.SpecificationsDimensions mm Fig n°

12-30VDC
AC

SPA07420

4A12-275VAC15-30VAC2100 Ω VDRAC output29x12,7x25,4112-30VDC

STA07220

2A 12-275VAC15-30VAC
2100 Ω
VDR AC output29x12,7x15,72

2

SPD03505

5A0-30VDC12-30VDC2100 Ω transilDC output29x12,7x25,41
DC

STD03205

2,5A0-30VDC12-30VDC2100 Ω transilDC output29x12,7x15,72 12-30VDC
AC/DC

STN07105

1A0-30VAC/DC15-30VAC2100 Ω transilAC/DC output29x12,7x15,72
ESD05000 ESC05000

PRODUCTREFERENCE SpecificationsFig n°

3

ESC05000

SP/ST base for PCB for one relay3

4

ESD05000

SP/ST base for DIN rail for one relay4

ESD08000

8 SP in line module base5
Interface cardboard

ESD16000

16 SP in line module base5

ESD16100

8 SP compact module base5

5 2

Our STD and SPD modules can be developped, on request, with an output voltage of 100VDC.Other control voltage on request.
