Type
2
m m
Max. working pressure
Operating pressure
Air treatment capacity
Standarc Dew Point
FMO 0,1 pm 0,1 mg/mc
FMM 0,01 pm 0,01 mg/mc
FPRE 1 pm n.a. mg/mc
Inlet / outlet connections
Dimensions
Weight
bar
psi
bar
m3/h
cfm
°C.
Pre filters
Post filter
gas
L
W
H
Kg
ADS 1
16
232
7,0
114
7
4,1
-40
n.a.
FMM 10
3/8"
281
92
445
13
ADS 2
16
232
7,0
168
10
5,9
-40
n.a.
FMM 10
"EGRATED IN T H E DRYER
3/8"
281
92
504
14
ADS 3
16
232
7,0
282
17
10
-40
n.a.
FMM 10
3/8"
281
92
635
17
ADS 4
16
232
7,0
426
26
15,3
-40
n.a.
FMM 10
3/8"
281
92
815
20
ADS 7
16
232
7,0
708
42
24,7
-40
n.a.
FMM 10
3/8"
281
92
1065
24
ADS 10
16
232
7,0
990
59
34,7
-40
n.a.
FMM 10
3/8"
281
92
1460
31
ADS 20
16
232
7,0
1920
115
67,7
-40
n.a.
FMM 20
FPRE 20
3/4"
550
177
998
50
ADS 24
16
232
7,0
2400
144
84,8
-40
n.a.
FMM 20
FPRE 20
3/4"
550
177
998
50
ADS 27
16
232
7,0
2700
162
95,3
-40
n.a.
FMM 33
FPRE 33
3/4"
550
177
1243
60
ADS 36
16
232
7,0
3600
216
127
-40
n.a.
FMM 33
FPRE 33
1"
550
378
999
100
ADS 42
16
232
7,0
4200
252
148
-40
n.a.
FMM 60
FPRE 60
1"
550
378
999
100
ADS 55
16
232
7,0
5400
324
191
-40
n.a.
FMM 60
FPRE 60
1"
550
378
1243
120
ADS 60
16
232
7,0
6000
360
212
-40
n.a.
FMM 60
FPRE 60
1 /"
550
540
998
150
ADS 80
16
232
7,0
7800
468
275
-40
n.a.
FM M 85
FPR E 85
1 /"
550
540
1243
180
ADS 110
11
159
7,0
10800
648
381
-40
FMO 130
FMM 130
FPRE 130
1 /"
960
754
1716
445
16
232
12,5
12900
774
456
ADS 130
11
159
7,0
13200
792
466
-40
FMO 130
FMM 130
FPRE 130
1 /"
960
754
1716
445
16
232
12,5
15900
954
561
ADS 180
11
159
7,0
18000
1.080
636
-40
FMO 170
FMM 170
FPRE 170
2"
1064
833
1832
600
16
232
12,5
21600
1.296
763
ADS 215
11
159
7,0
21600
1.296
763
-40
FMO 250
FMM 250
FPRE 250
2"
1118
859
1869
650
16
232
12,5
25800
1.548
911
Notes:
1 Reference conditions:
- Operating pressure: see the technical data table.
- Operating temperature: 35°C.
- Relative humidity: 100%
© Filters are delivered loose with the dryer:
ADS1-10: the filters can be directly fixed on the dryer . ADS20-215: the filters have to be mounted on the air distribution line.
For working pressure different from " operating pressure " use the correction factors table.
X
U
H
Correction factors
ADS/16 bar
Air Inlet Pressure - bar
4
5
6
7
8
9
10
11
12
13
14 15
16
ADS 1 u p ADS 80
0,62
0,75
0,87
1
1,12
1,25
1,37
1,5
1,62
1,75
1,87 2
2,12
Correction factors
ADS/11 bar
ADS/16 bar
Air Inlet Pressure - bar
4
5
6
7
8
9
10
11
1 1
12,5
13 14
15
ADS110 up to ADS215
0,47
0,68
0,84
1
1,1
1,2
1,3
1,38
0,89
1
1,04 1,11
1,19
Correction factors
Air Inlet Temperature °C.
20
25
30
35
40
45
50
ADS1 up to ADS10
ADS20 up to ADS215
1,07
1
1,06
1
1,04
1
1 1
0,88 0,84
0,78 0,71
0,55 0,55
W
16
