13 Windshield Washers/Wipers. 14 Rear Vision Camera Monitor. Within-the-blade washer delivery system are standard features on front and rear windows. The front wiper hasintermittent speed capability. Connected to a camera mounted on theradiator guard, this monitor allows the operator to see the area behind themachine. 9 Built-In Storage Space. 12 Decelerator Pedal. On the left acts asboth an engine decelerator and a brake that overrides the engine speed selected by the throttle lock. This enables the operator to slow down when throttle lock is engaged and to return to throttle lock without pressing a button. It aids in maneuvering around shovels, haul trucks, tractors or any other obstacle. Is designedtohold cups, lunch box, insulated bottle and personal items. 10 Repositioned Vents. 11 Throttle Lock. Allows and operatortoset the engine speed and remove his foot from the governor (accelerator) pedal much like cruise control on an automobile. Using this feature increases productivity, fuel efficiency and improves operator comfort. Throughoutthecab keep fresh air flowing while improving the cab’s heating, cooling, defrost and defog capability. 7 Pilot-Operated Blade Controls. 6 Steering Column. Areconveniently located and allow forprecise blade movement. 8 Operator Seat. Is designed for comfortand support. Seat cushions reduce pressure on the lower back and thighs while allowing unrestricted arm and legmovement.•A fully adjustable air suspensionseat with self-contained compressor is available as an option. Adjusts to multiplepositions. The leather-like steering wheel and transmission control provide a sure grip and comfortable feel. Thehorn is conveniently located in thecenter of the steering wheel. 3 Quick Gear Kick Up/Down Button. 4 Ignition Key Start/Stop Switch. Lets the operator easily downshift orupshift to a different gear. It is a convenient way to shift that saves timeand effort. Ispositioned for easy machine starting andstopping. 5 12-Volt Power Supply and CatElectronic Technician (ET) Diagnostics. Is provided inside the cab for powering radios, telephones or a laptop computer. This is particularly useful for powering a laptop running Cat ET to access the enhanced engine and transmission control system diagnostics. 1 Exceptional All-Around Viewing Area. Reduces strain and fatigue, making operators more productive. 2 Caterpillar Monitoring System. Withelectronic analog gauges is a highly effective and reliable warning and diagnostic system.As a warning system, it constantlychecks machine functions and tells theoperator when there is a problem. Easy-to-read gauges display fuel level, temperatures for engine coolant, transmission and hydraulic oil, engine rpm and gear range. Hour meter, odometer and analog tachometer readings are also displayed.As a diagnostic system, it identifiesconditions, shows current readings andplays back maximum or highest readings registered during recent operations.The right side panel contains a threelevel warning system, providing full-time monitoring of key functions. The system alerts the operator of immediate or impending problems with air inlet temperature, brake oil pressure, electrical system, low voltage, engine oil pressure, engine over-speed, fuel filter status, parking brake status, steering oil pressure and transmission filter status.

Wheel Dozer - 19427 9
