GAS Ratings Definitions
OLYMPIAN NORTH AMERICA
60 Hz GAS RATINGS, 25 kVA - 150 kVA
GAS 15
G AS 60 Hz - Nor th America
14 GAS
GAS RATINGS DEFINITIONS
Standby Rating
These ratings are applicable to variable loads for the duration of a
power outage. There is no overload capability for this rating. Ratings are
in accordance with ISO - 3046-1.
Gas Rating
Ratings based on LPG fuel and may derate with natural gas. Please
contact dealer for natural gas rating.
Standby Generator
RPM NG kVA (ekW) LP kVA (ekW) Set Model
3-Phase Output
1800 25 (20) 25 (20) *G25LTA
1800 55 (44) 55 (44) *G55LTA
1800 70 (56) 70 (56) *G70LTA
2650 80 (64) 80 (64) *G80LTA
2300 100 (80) 100 (80) *G100LTA
3000 130 (104) 130 (104) *G130LTA
3600 150 (120) 150 (120) *G150LTA
Standby Generator
RPM NG kVA (ekW) LP kVA (ekW) Set Model
3-Phase Output
1800 70 (56) 70 (56) *G70LG
2300 80 (64) 80 (64) ***G80LG
2300 100 (80) 100 (80) *G100LG
3000 130 (104) 130 (104) *G130LG
3600 150 (120) 150 (120) *G150LG
1800 175 (140) 175 (140) ***G175LG
1800 200 (160) 200 (160) ***G200LG
2300 230 (184) 230 (184) ***G230LG
2300 250 (200) 250 (200) ***G250LG
2300 275 (220) 275 (220) ***G275LG
2300 300 (240) 300 (240) ***G300LG
*Ratings at 0.8 pf and 25° C (77° F)
**Ratings at 0.8 pf and 40° C (104° F)
***Ratings at 0.8 pf and 43° C (110° F)
LTA Models (Sta ndard)
LG Models (Customizable)
OLYMPIAN NORTH AMERICA
60 Hz GAS RATINGS, 70 kVA - 300 kVA
