Capacitec 4100-SLC/4101-SLC Signal Conditioner Specifications - 1 Pages

sales@Capacitec.com 87 Fitchburg Road PO Box 819 Ayer, MA 01432 www.Capacitec.com
4100-SLC/4101-SLC SPECIFICATIONS
Description:
The 4100-SLC is a self-contained signal conditioner with a built in oscillator/demodulator and
Linearizer designed primarily for use in low volume, single point measurement applications. The 4100-
SLC is compatible with all new and existing Capacitec Sensor probes and Thin Film Wands. The 4101-
SLC version adds a 4-1/2 digit LED display.
Power Requirements: +5VDC @±200mA (universal power supply included)
Operating Temperature: 0-35°C
Temperature Stability: -1.0mV per degree C typical (or better)
Physical Dimensions: 241mm X 108mm X 32mm (9.5" X 4.25" X 1.25")
Output: 0-10Vdc (+/-5 Vdc opt.); proportional to sensing gap.
Includes a 10Vdc offset control.
Range: Typically 100% of probe's sensor diameter or diametrical
area equivalent. 2/3 of sensor diameter for best linearity
Linearity: Typically ±0.2% of full scale or better with 2/3 range
calibration.
Frequency Response: 232Hz standard; 3.1KHz optional (-3dB point)
Output Resolution: 1 mVdc
Display: 1.0000, 10.000 100.00
