Hose Fittings Connectors DE 40 0008 12/2006 Page 1/4 In properly designed and constructed sample conditioning systems, the internal tubing must conform to the same high standards required for components such as sample pumps, filters, etc. The connections must seal properly and reliably and the fittings must integrate easily with the components. Bühler fittings are available in a variety of materials and are designed using reliable fastening principles. On PPand PVDF fittings, the hose slides over a center pin that provides reinforcement and keeps the tubing in proper geometric from. A tapered ring secures the tubing when the cap is tightened. PFA fittings use two tapered rings that keep the hose tight after the cap is tightened. : W lyes cids cids lyes, sample gases, , Construction Materials §Polypropylene (PP) Polyvinylidene Fluoride (PVDF) Polyfluoroalkoxy (PFA) Uses ater, solvent, Uses: A clean water, VE - water, lacquers, colors Uses: A , corrosive gases § § ® Bühler Technologies GmbH D - 40880 Ratingen, Harkortstr. 29 Tel.: + 49 (0) 2102 / 49 89-0 Fax: + 49 (0) 2102 / 4989-20 e-mail: analyse@buehler-ratingen.com
