Accessories Racking Groups

There are two machined rack torch mounting groups in the Modular Drive System, one for plasma or oxy- fuel cutting and the other for welding.

Machined Rack Cutting Group

Order reference: MDS-1050

Remote Control Cable

Installs between the Master Drive Unit and the Control Module, allowing the operator to perform work in confined areas where it would be difficult to reach the controls. Two sizes are available as shown below.Order reference:

Machined Rack Welding Group

MDS-1060-10 10 Ft (3 m) MDS-1060-25 25 Ft (7.6 m)
Order reference: MDS-1040

Spacer w/Screws Quick Action Manifold

Provides height required to position racking group for plasma cutting applications.Order reference: Allows quick ON/OFF of preset torch and eliminates hose strain.Order reference:

Universal Limit Kit

PAN-1001 Installs between the Master Drive Unit and any of the control modules. This limit kit adds the ability to cycle between limits, stop at limit, or rapid return. All existing functions of the control modules are maintained.Order reference: MDS-3025 2-Hose MDS-9898 MDS-1055 For Rigid Rail Applications 3-HoseHose Assemblies: FMD-1045 For Hi-Flex Rail Applications (not shown)

Weld Contact Cable

CIR-1010-3 2-Hose MUG-1119-32 3-Hose Order reference: MDS-1085 10' MDS-1085-25 25' MDS-1085-50 50'

Extended Mounting Plate Handle with Cable Anchor

Mounts to front of the carriage for use with dual cutting or welding groups, heavy duty racking, etc.Order reference: Keeps welding cables and contact wires away from the work surface, eliminating drag.Order reference: MDS-1045 MPD-1035
A QUALITY PRODUCT FROM BUG-O SYSTEMS

•

280 TECHNOLOGY DRIVE

•

CANONSBURG, PA 15317-9564 USA A DIVISION OF WELD TOOLING CORPORATION © Weld Tooling Corp. ROM 1:16 Litho in U.S.A. LIT-MDS-BRO-1208
