Carriages

Aluminum Rigid and Semi-Flex Rail Carriages

Two carriages are available for the Modular Drive System when using BUG-O Aluminum Rigid and Semi-Flex Rails.* One is a releasable 12” carriage equipped with an engagement knob that allows the unit to be placed anywhere along the track. Also available is an 18” carriage which has an extended deck for mounting accessories, wire feeders, etc. (MPD-1055)

MPD-1065 Releasable Carriage 12" on Aluminum Rigid Rail. Order reference: MPD-1065 Releasable Carriage 12"

Hi-Flex Carriages

Hi-Flex carriages are designed for use with the Modular Drive System when running the equipment on BUG-O Hi-Flex Stainless Steel Rail.* Each carriage has a built-in quick release for mounting or removal at any point along the rail. A cable anchor is also included to keep welding cables and contact wires away from the work surface.

FMD-1105 Flex Rail Carriage w/Cable Anchor on Hi-Flex Rail. Order reference: FMD-1105 Drive Carriage

Bent Aluminum Rigid Rail Carriages

For applications using the Modular Drive System on BUG-O Bent Aluminum Rigid Rail,* a split carriage is available. This releasable carriage can be placed anywhere along the track and easily adjusts to various work diameters. (For outside radii only)

BUG-5910 Tube Carriage on Bent Aluminum Rigid Rail. Order reference: BUG-5910 Tube Carriage
* Note: see Rails and Attachments brochure for information on BUG-O Systems rails. 5
