Assembling a Modular Drive System is Easy!

Choose from the options below to fit your application.

Modular Drive System - 11660 1

Control Modules

MDS-1002 MDS-1004 MDS-1005 Straight Line Module Programmable Stitch Module Weaver Control Module Choose from the following options: CuttingMDS-1050

2

Machined Rack Cutting Group

Master Drive Units

MPD-1000 120 VAC WeldingMDS-1040 MPD-1002 240 VAC Machined Rack Welding Group Weave Welding (Use MDS-1005 Weaver Control Module) WPD-1100

3

Linear Weaveror

Carriages

WPD-2100 Pendulum Weaver II FMD-1105 MPD-1065 Hi-FlexCarriage 12" ReleasableCarriage BUG-5910 Tube Carriage

4

Rails

FMD-1050 ARR-1080 AFR-3000 BRR-1180 Hi-Flex Rail Aluminum Rigid Rail 8' Semi-Flex Rail Bent Rigid Rail ARR-1085 Aluminum Rigid Rail 4'

5

Attachments

For more information on vacuum cups, magnets and rails, please see the corresponding rail page in the “Rails and Attachments” brochure in order to match the correct attachments with your rails. FMD- FMD- ARV- ARM- Vacuum Cups Magnets Vacuum Cups Magnets 3
