BRUKER

■ smartbeam laser technology: Top performance with any chosen matrix, outclassing the conventional YAG-only laser PAN: highest mass resolution at every mass from 700 - 6,000 Da HPC: High Precision Calibration for highest mass accuracy

smartbeam laser with adjustable repetition rate from 1-200 Hz. Resolution > 1,100 and mass accuracy of < 80 ppm in linear mode for protein samples; a prerequisite for MALDI Imaging and Biomarker Profiling workflows Resolution > 25,000 using Bruker Daltonics' unique PAN™ (panoramic) technology

Mass accuracy of<3 ppm for peptide mass range in reflectron mode Sensitivity in low attomole range with high signal-to-noise ratio in TOF/TOF mode

■ flexControl module for quick and easy instrument control

■ flexAnalysis module for automatic and interactive data analysis

Optional packages:

■ BioTools™, the cutting edge software for protein analysis

■ WARP-LC™, the LC-MALDI and protein quantitation software

■ ClinProTools™, the software for biomarker visualization and discovery

■ flexlmaging™, the software for MALDI imaging applications

■ ProteinScape database system for proteomics project management

■ Compass Security Pack, supports 21CFR part 11 compliance

■ Extended self diagnostics

■ Remote on-line service capability

■ Supplementary IQ/OQ/PV procedures available

■ Custom-tailored maintenance contracts available

■ MALDI Molecular Imager - Mass Spectrometry-Based Imaging

■ CLINPROT- Mass Spectrometry-Based BiomarkerAnalysis « PROTEINEER-LC- LC-based Proteomics Suite

« PROTEINEER - 2D Gel-based Proteomics Suite

For research use only. Not for use in diagnostic purposes.

Ultimate Productivity in Proteomics

Bremen ■ Germany Phone +49 (421)2205-0 Fax +49 (421) 2205-103 sales@bdal.de

Billerica, MA ■ USA Phone +1 (978) 663-3660 Fax +1 (978) 667-5993 ms-sales@bdal.com

MALDI-TOF/TOF MS

think forward
