1 Data Sheet DS-VA-1350E-eng March, 2008 Models 1350E and 1355E • Ten-to-one rangeability • Heavy-wall, precision bore, borosilicate glass metering tubes • A wide range of scales on the metering tube with contrasting background for easy readability • Tubes sealed on compression gasket by threaded seal spindle • Tubes removable without disconnecting instrument • Integral float stops prevent loss of float during tube removal • Interchangeable tubes and floats DESCRIPTION The Sho-Rate 1350 and 1355 Series of low flow indicators provides a cost-effective means of flow indication for both 5% (Model 1355) and 10% (Model 1350) accuracy requirements. Available options include the Standard or NRSTM integral needle control valves, as well as flow controllers on the inlet or outlet. SPECIFICATIONS Capacities 1350 Series: Refer to Tables 1 or 2, or 3 and 4 1355 Series: Refer to Tables 3 and 4, or 5 Accuracy 1350 Series Standard: Accuracy of ±10% of full scale from 100% to 10% of scale reading 1355 Series Standard: ±5% of full scale from 100% to 10% of scale reading Repeatability 0.5% full scale Rangeability 10 to 1 Pressure 200 psig at temperatures up to 250°F Pressure Drop Inquire at factory Flow Meter Assembly Pressure Equipment Directive (97/23/EC) Note: Equipment falls under Sound Engineering Practice (SEP) according to the directive. Model 1355E Sho-Rate "150" (No valve) Model 1355E-8800 Sho-Rate "150" with optional integral flow controller Model 1350E Sho-Rate "50" (No valve) Model 1350E-8800 Sho-Rate "50" with optional integral flow controller Model 1350E Sho-Rate "50" with optional needle valve Model 1353E Sho-Rate "150" with optional needle valve Sho-RateTM "50" Model 1350E and Sho-RateTM "150" Model 1355E
